MX-3610N ADJUSTMENTS AND SETTINGS 4 – 93
3) Enter an adjustment value and press [OK] key.
4) Cancel the simulation, make a copy in the mode including the adjustment target, and check the adjustment result.
L PUNCH HOLE Punch hole
position
adjustment
30 - 60 50 When the punch
hole position is
shifted in the
transport direction,
the adjustment is
executed.
Punch position
(paper transport
direction)
When the adjustment value is
increased, the punch hole
position is shifted to the rear
edge of paper.
When the adjustment value is
decreased, the punch hole
position is shifted to the lead
edge of paper.
0.2mm
MSADDLE_
ADJUST_POS
Saddle alignment
position
adjustment
35 - 65 50 When the paper
alignment capability
in the saddle
section is improper,
the paper alignment
width is adjusted.
Saddle paper
alignment plate stop
position
(F/R direction)
When the adjustment value is
increased, the alignment plate
position is shifted to the
center.
When the adjustment value is
decreased, the alignment
plate position is shifted to the
outside.
0.2mm
N GRIPPER_
POS
Gripper exit
position
adjustment
35 - 65 50 When the gripper
discharge position is
shifted, the
adjustment is
executed. (When a
JAM or trouble
occurs, the
adjustment is
executed.)
Gripper discharge
position (Gripper
stop position)
(F/R direction)
When the adjustment value is
increased, the gripper
discharge position is shifted to
the front.
When the adjustment value is
decreased, the gripper
discharge position is shifted to
the rear.
0.2mm
Item/Display Content
Setting
range
Default
value
Purpose
(Case where the
adjustment is
required)
Change when the adjustment value is increased
or decreased
Change when
the adjustment
value is
changed by 1
