MX-3610N CONSUMABLE PARTS 2 – 19
When shipping, the parts are packed in the unit of 10 sets. In the market, however, they are treated in the unit of 1 set.
Model name: Composed of the parts of 1 set
The numbers in the column of "Quantity in collective package" in the above list indicate the quantities for one package shipped from the factory.
Since, however, the products are treated as one piece or one set, their model names and necessary quantities must be specified when order-
ing. Pay attention to that.
3. Definition of developer/drum life end
When the developer/drum counter reaches the specified count.
When the developer/drum rpm reaches the specified count.
When either of the above reach the specified count, it is judged as
life end.
In an actual case, the ratio of monochrome output and color output
may differ greatly.
When data of mixed documents (monochrome and color) are out-
put, monochrome document data may be output in the color mode
in order to prevent against fall in the job efficiency. (ACS auto color
selection).
In addition, when correction or warm-up operation is performed as
well as output operation, the developer and the drum rotates.
Therefore, the developer/drum consuming level cannot be deter-
mined only by the copy/print quantity. When, therefore, the rpm
reaches the specified amount, it is judged as life end.
To check the developer/drum life, use SIM22-13.
A. 18cpm machine
B. 20cpm machine
Primary transfer belt unit MX-230U1 Primary transfer belt unit (For servicing rotation) x 1 — 1
Secondary transfer belt unit MX-230U2 Secondary transfer belt unit (For servicing rotation) x 1 — 1
Fusing unit MX-360FU Fusing unit (For servicing rotation: Heater lamp 230V) x 1 — 1
Item
Model
name
Content Life
Quantity in
collective
package
Remarks
Developer/drum counter Developer/drum rpm
B/W Full color B/W Full color
Developer/
drum
80K 50K 840K
rotations
840K
rotations
Kind of multi Black drum Color drum
Single multi 58000 38000
2 sheets multi 80000 50000
