MX-3610N EXTERNAL VIEW AND INTERNAL STRUCTURE 3 – 15
7. Clutches and solenoids
A. 18cpm/20cpm/23cpm/26cpm/31cpm machine
(1) 18cpm/20cpm machine
1TURC_2
SRRC
SPRS
STMPS
1TURC_1
MPFS
RRC
2TURC
ADUC1
CPUC1
PFC_HPFC
CPFC1
