MX-3610N EXTERNAL VIEW AND INTERNAL STRUCTURE 3 – 40
15. Fuses and Thermostats
A. 18cpm/20cpm/23cpm/26cpm/31cpm machine
(1) 18cpm/20cpm machine
F1
F2
TS LM
TS UM
F001
F003
F101
F401
F201
F202
F203
F204
F205
TS US
