MX-3610N CONSUMABLE PARTS 2 – 9
When shipping, the parts are packed in the unit of 10 sets. In the market, however, they are treated in the unit of 1 set.
Model name: Composed of the parts of 1 set
(2) Singapore, Thailand, Malaysia, India, Middle east, Other countries
When shipping, the parts are packed in the unit of 10 sets. In the market, however, they are treated in the unit of 1 set.
Model name: Composed of the parts of 1 set
(3) Hong Kong
When shipping, the parts are packed in the unit of 10 sets. In the market, however, they are treated in the unit of 1 set.
Model name: Composed of the parts of 1 set
Item
Model
name
Content Life
Quantity in
collective
package
Remarks
Upper heat roller kit MX-200UH Upper heat roller x 1 100K 10
Lower heat roller kit MX-200LH Lower heat roller x 1 100K 10
Fusing cleaning kit MX-230CR Lower oil roller x 1 100K 10
Lower CL roller x 1
Lower CL roller bearing x 2
Lower CL scraper x 1
Primary transfer belt kit MX-230B1 Primary transfer belt AR x 1 100K 10
Primary transfer blade kit MX-230TL Primary transfer blade AR x 1 100K 10
PTC kit MX-230CU PTC unit x 1 100K 10
Secondary transfer belt kit MX-230B2 Secondary transfer belt D3 x 1 300K 10
PS paper dust removing unit MX-230PD PS paper dust removing unit x 1 100K 10
Filter kit MX-C31FL Ozone filter x 1 100K 10
Toner collection container MX-230HB Toner collection container (with LSU cleaner x 2) x 1 50K 5 5% coverage for each
color; 25% color ratio
Main charger kit MX-230MK Main charger unit x 1 Black: 100K
Color: 60K
10
Cleaning gum AS AR x 1
Cleaning blade AR x 1
Staple cartridge MX-SCX1 Staple cartridge x 3 5000 times
x 3
20 For MX-FN17
Finish stamp cartridge AR-SV1 Finish stamp cartridge x 2 — 20
Primary transfer belt unit MX-230U1 Primary transfer belt unit (For servicing rotation) x 1 — 1
Secondary transfer belt unit MX-230U2 Secondary transfer belt unit (For servicing rotation) x 1 — 1
Fusing unit MX-200FU1 Fusing unit (For servicing rotation: Heater lamp 120V) x 1 — 1
Fusing unit MX-200FU Fusing unit (For servicing rotation: Heater lamp 230V) x 1 — 1
Item
Model
name
Content Life
Quantity in
collective
package
Remarks
Upper heat roller kit MX-200UH Upper heat roller x 1 100K 10
Lower heat roller kit MX-200LH Lower heat roller x 1 100K 10
Fusing cleaning kit MX-230CR Lower oil roller x 1 100K 10
Lower CL roller x 1
Lower CL roller bearing x 2
Lower CL scraper x 1
Primary transfer belt kit MX-230B1 Primary transfer belt AR x 1 100K 10
Primary transfer blade kit MX-230TL Primary transfer blade AR x 1 100K 10
PTC kit MX-230CU PTC unit x 1 100K 10
Secondary transfer belt kit MX-230B2 Secondary transfer belt D3 x 1 300K 10
PS paper dust removing unit MX-230PD PS paper dust removing unit x 1 100K 10
Filter kit MX-C31FL Ozone filter x 1 100K 10
Toner collection container MX-230HB Toner collection container (with LSU cleaner x 2) x 1 50K 5 5% coverage for each
color; 25% color ratio
Main charger kit MX-230MK Main charger unit x 1 Black: 100K
Color: 60K
10
Cleaning gum AS AR x 1
Cleaning blade AR x 1
Staple cartridge MX-SCX1 Staple cartridge x 3 5000 times
x 3
20 For MX-FN17
Finish stamp cartridge AR-SV1 Finish stamp cartridge x 2 — 20
Primary transfer belt unit MX-230U1 Primary transfer belt unit (For servicing rotation) x 1 — 1
Secondary transfer belt unit MX-230U2 Secondary transfer belt unit (For servicing rotation) x 1 — 1
Fusing unit MX-200FU Fusing unit (For servicing rotation: Heater lamp 230V) x 1 — 1
