Sharp MX-3111U Service Manual

MX-3610N CONSUMABLE PARTS 2 – 11
When shipping, the parts are packed in the unit of 10 sets. In the market, however, they are treated in the unit of 1 set.
Model name: Composed of the parts of 1 set
(3) Asia, Middle East
When shipping, the parts are packed in the unit of 10 sets. In the market, however, they are treated in the unit of 1 set.
Model name: Composed of the parts of 1 set
(4) Hong Kong
Primary transfer belt unit MX-230U1 Primary transfer belt unit (For servicing rotation) x 1 — 1
Secondary transfer belt unit MX-230U2 Secondary transfer belt unit (For servicing rotation) x 1 — 1
Fusing unit MX-230FU Fusing unit (For servicing rotation: Heater lamp 230V) x 1 — 1
Item
Model
name
Content Life
Quantity in
collective
package
Remarks
Fusing belt kit MX-230FB Fusing belt x 1 100K 10
Fuser belt guide collar x 2
Pressure roller kit MX-230LH Fusing roller x 1 200K 10
Pressure roller x 1
Fusing cleaning kit MX-230CR Lower oil roller x 1 100K 10
Lower CL roller x 1
Lower CL roller bearing x 2
Lower CL scraper x 1
Primary transfer belt kit MX-230B1 Primary transfer belt AR x 1 100K 10
Primary transfer blade kit MX-230TL Primary transfer blade AR x 1 100K 10
PTC kit MX-230CU PTC unit x 1 100K 10
Secondary transfer belt kit MX-230B2 Secondary transfer belt D3 x 1 300K 10
PS paper dust removing unit MX-230PD PS paper dust removing unit x 1 100K 10
Filter kit MX-C31FL Ozone filter x 1 100K 10
Toner collection container MX-230HB Toner collection container (with LSU cleaner x 2) x 1 50K 5 5% coverage for each
color; 25% color ratio
Main charger kit MX-230MK Main charger unit
Cleaning gum AS AR
Cleaning blade AR
x 1
x 1
x 1
Black: 100K
Color: 60K
10
Staple cartridge MX-SCX1 Staple cartridge x 3 5000 times
x 3
20 For MX-FN17
Finish stamp cartridge AR-SV1 Finish stamp cartridge x 2 — 20
Primary transfer belt unit MX-230U1 Primary transfer belt unit (For servicing rotation) x 1 — 1
Secondary transfer belt unit MX-230U2 Secondary transfer belt unit (For servicing rotation) x 1 — 1
Fusing unit MX-230FU1 Fusing unit (For servicing rotation: Heater lamp 120V) x 1 — 1
Fusing unit MX-230FU Fusing unit (For servicing rotation: Heater lamp 230V) x 1 — 1
Item
Model
name
Content Life
Quantity in
collective
package
Remarks
Fusing belt kit MX-230FB Fusing belt x 1 100K 10
Fuser belt guide collar x 2
Pressure roller kit MX-230LH Fusing roller x 1 200K 10
Pressure roller x 1
Fusing cleaning kit MX-230CR Lower oil roller x 1 100K 10
Lower CL roller x 1
Lower CL roller bearing x 2
Lower CL scraper x 1
Primary transfer belt kit MX-230B1 Primary transfer belt AR x 1 100K 10
Primary transfer blade kit MX-230TL Primary transfer blade AR x 1 100K 10
PTC kit MX-230CU PTC unit x 1 100K 10
Secondary transfer belt kit MX-230B2 Secondary transfer belt D3 x 1 300K 10
PS paper dust removing unit MX-230PD PS paper dust removing unit x 1 100K 10
Filter kit MX-C31FL Ozone filter x 1 100K 10
Toner collection container MX-230HB Toner collection container (with LSU cleaner x 2) x 1 50K 5 5% coverage for each
color; 25% color ratio
Item
Model
name
Content Life
Quantity in
collective
package
Remarks
