MX-3610N CONSUMABLE PARTS 2 – 14
(4) Hong Kong
When shipping, the parts are packed in the unit of 10 sets. In the market, however, they are treated in the unit of 1 set.
Model name: Composed of the parts of 1 set
The numbers in the column of "Quantity in collective package" in the above list indicate the quantities for one package shipped from the factory.
Since, however, the products are treated as one piece or one set, their model names and necessary quantities must be specified when order-
ing. Pay attention to that.
E. 26cpm/31cpm(A) machine
(1) North America, Middle America, South America
Item
Model
name
Content Life
Quantity in
collective
package
Remarks
Fusing belt kit MX-360FB Fusing belt x 1 200K 10
Fuser belt guide collar x 2
Pressure roller kit MX-230LH Fusing roller x 1 200K 10
Pressure roller x 1
Fusing cleaning kit MX-230CR Lower oil roller x 1 100K 10
Lower CL roller x 1
Lower CL roller bearing x 2
Lower CL scraper x 1
Primary transfer belt kit MX-230B1 Primary transfer belt AR x 1 100K 10
Primary transfer blade kit MX-230TL Primary transfer blade AR x 1 100K 10
PTC kit MX-230CU PTC unit x 1 100K 10
Secondary transfer belt kit MX-230B2 Secondary transfer belt D3 x 1 300K 10
PS paper dust removing unit MX-230PD PS paper dust removing unit x 1 100K 10
Filter kit MX-C31FL Ozone filter x 1 100K 10
Toner collection container MX-230HB Toner collection container (with LSU cleaner x 2) x 1 50K 5 5% coverage for each
color; 25% color ratio
Main charger kit MX-230MK Main charger unit
Cleaning gum AS AR
Cleaning blade AR
x 1
x 1
x 1
Black: 100K
Color: 60K
10
Staple cartridge MX-SCX1 Staple cartridge x 3 5000 times
x 3
20 For inner finisher
(MX-FN17)
Finish stamp cartridge AR-SV1 Finish stamp cartridge x 2 — 20
Primary transfer belt unit MX-230U1 Primary transfer belt unit (For servicing rotation) x 1 — 1
Secondary transfer belt unit MX-230U2 Secondary transfer belt unit (For servicing rotation) x 1 — 1
Fusing unit MX-260FU Fusing unit (For servicing rotation: Heater lamp 230V) x 1 — 1
Item
Model
name
Content Life
Quantity in
collective
package
Remarks
Fusing belt kit MX-360FB Fusing belt x 1 200K 10
Fuser belt guide collar x 2
Pressure roller kit MX-230LH Fusing roller x 1 200K 10
Pressure roller x 1
Fusing cleaning kit MX-230CR Lower oil roller x 1 100K 10
Lower CL roller x 1
Lower CL roller bearing x 2
Lower CL scraper x 1
Primary transfer belt kit MX-230B1 Primary transfer belt AR x 1 100K 10
Primary transfer blade kit MX-230TL Primary transfer blade AR x 1 100K 10
PTC kit MX-230CU PTC unit x 1 100K 10
Secondary transfer belt kit MX-230B2 Secondary transfer belt D3 x 1 300K 10
PS paper dust removing unit MX-230PD PS paper dust removing unit x 1 100K 10
Filter kit MX-C31FL Ozone filter x 1 100K 10
Toner collection container MX-230HB Toner collection container (with LSU cleaner x 2) x 1 50K 5 5% coverage for each
color; 25% color ratio
Main charger kit MX-360MK Main charger unit
Cleaning gum AS AR
Cleaning blade AR
x 1
x 1
x 1
Black: 100K
Color: 60K
10
Staple cartridge AR-SC3 Staple cartridge x 3 2000 times
x 3
40 For saddle finisher
(MX-FN10)
Staple cartridge MX-SCX1 Staple cartridge x 3 5000 times
x 3
20 For saddle finisher
(MX-FN10) and inner
finisher (MX-FN17)
Finish stamp cartridge AR-SV1 Finish stamp cartridge x 2 — 20
