MX-3610N EXTERNAL VIEW AND INTERNAL STRUCTURE 3 – 7
B. 26cpm/36cpm/31cpm(A) machine
No. Name Function/Operation
1 Touch panel Messages and keys appear in the touch panel display.
Touch the displayed keys to perform a variety of operations.
When a key is touched, a beep sounds and the selected item is highlighted. This provides confirmation as you
perform an operation.
2 Main power indicator This lights up when the machine's main power switch is in the "on" position.
3 [POWER] key ( ) Use this key to turn the machine power on and off.
4 [POWER SAVE] key ( ) / indicator Use this key to put the machine into auto power shut-off mode to save energy.
The [POWER SAVE] key ( ) blinks when the machine is in auto power shut-off mode.
5 [HOME] key / indicator Touch this key to display the home screen.
Frequently used settings can be registered in the home screen to enable quick and easy operation of the
machine.
(1) (2)
(5)
(3) (4)
To Next Page
