MX-3610N ADJUSTMENTS AND SETTINGS 4 – 9
3) Enter the adjustment value (specified value), and press [OK] key.
When [EXECUTE] key is pressed, the voltage entered in the procedure 3) is outputted for 30sec and the set value is saved.
When [EXECUTE] key is pressed again, the output is stopped.
By setting the default value (specified value), the specified output is provided.
K TC2 PLAIN CL SPX Secondary
transfer
bias
adjustment
value
Color Standard
paper
Front surface 51 - 255 96 –35A 103 –40A 110 –45A
L TC2 PLAIN CL DPX Back surface 51 - 255 76 –20A90–30A 96 –35A
M TC2 PLAIN BW SPX Black/White Front surface 51 - 255 96 –35A 103 –40A 110 –45A
N TC2 PLAIN BW DPX Back surface 51 - 255 76 –20A90–30A 96 –35A
O TC2 HEAVY1 CL SPX Color Heavy
paper 1
Front surface 51 - 255 83 –25A83–25A 83 –25A
P TC2 HEAVY1 CL DPX Back surface 51 - 255 76 –20A76–20A 76 –20A
Q TC2 HEAVY1 BW SPX Black/White Front surface 51 - 255 69 –15A69–15A 69 –15A
R TC2 HEAVY1 BW DPX Back surface 51 - 255 69 –15A69–15A 69 –15A
S TC2 HEAVY2 CL Color Heavy paper 2 51 - 255 83 –25A83–25A 83 –25A
T TC2 HEAVY2 BW Black/White 51 - 255 69 –15A69–15A 69 –15A
U TC2 OHP CL Color OHP 51 - 255 69 –15A69–15A 69 –15A
V TC2 OHP BW Black/White 51 - 255 69 –15A69–15A 69 –15A
W TC2 ENVELOPE CL Color Envelope 51 - 255 69 –15A69–15A 69 –15A
X TC2 ENVELOPE BW Black/White 51 - 255 69 –15A69–15A 69 –15A
Y
TC2 THIN CL Color Thin paper 51 - 255 96 –35A 103 –40A 110 –45A
Z TC2 THIN BW Black/White 51 - 255 96 –35A 103 –40A 110 –45A
AA TC2 GLOSSY CL Color Gloss paper 51 - 255 83 –25A83–25A 83 –25A
AB TC2 GLOSSY BW Black/White 51 - 255 69 –15A69–15A 69 –15A
AC TC2 CLEANING Secondary
transfer
cleaning
bias
adjustment
value
Cleaning process (negative pole) 51 - 255 59 –8A59–8A59–8A
AD TC2 CLEAN LOW SPD Low speed print mode 0 - 255 26 0V 26 0V 26 0V
AE TC2 CLEAN MIDDLE
SPD
Middle speed print mode 0 - 255 26 0V 26 0V 26 0V
AF TC2 CLEAN
CLEANING
Cleaning bias (positive pole) 0 - 255 102 500V 102 500V 102 500V
AG PTC LOW SPEED CL PTC
current
adjustment
value
Color Low speed 51 - 255 73 –200A 73 –200A 73 –200A
AH PTC MIDDLE SPEED
CL
Middle speed 51 - 255 73 –200A 73 –200A 73 –200A
AI PTC LOW SPEED BW Black/White Low speed 51 - 255 73 –200A 73 –200A 73 –200A
AJ PTC MIDDLE SPEED
BW
Middle speed 51 - 255 73 –200A 73 –200A 73 –200A
AK CASE VOLT LOW CL PTC
voltage
adjustment
value
Color Low speed 0 - 255 0 0V 0 0V 0 0V
AL CASE VOLT MID CL Middle speed 0 - 255 0 0V 0 0V 0 0V
AM CASE VOLT LOW BW Black/White Low speed 0 - 255 0 0V 0 0V 0 0V
AN CASE VOLT MID BW Middle speed 0 - 255 0 0V 0 0V 0 0V
Item/Display Content
Setting
range
18cpm/20cpm/
23cpm machine
26cpm/31cpm
machine
36cpm machine
Default
value
Actual
output
value
Defaul
t
value
Actual
output
value
Default
value
Actual
output
value
