MX-5001N SIMULATION 6 – 8
3. Details of simulation
1
1-1
Purpose
Operation test/check
Function (Purpose)
Used to check the operation of the scanner
(reading) unit and the control circuit.
Section
Scanner (reading)
Operation/Procedure
1) Select the operation speed with the touch panel key.
2) Press [EXECUTE] key.
Scanning is once performed at the speed corresponding to the
scan resolution (operation speed).
1-2
Purpose
Operation test/check
Function (Purpose)
Used to check the sensors in the scanner
(reading) section and the related circuits.
Section
Scanner (reading)
Operation/Procedure
The operating status of the sensor is displayed.
When "MHPS" is highlighted, the scanner unit is in the home posi-
tion.
1-5
Purpose
Operation test/check
Function (Purpose)
Used to check the operation of the scanner
(reading) unit and the control circuit.
Section
Scanner (reading)
Operation/Procedure
1) Select the operation speed with the touch panel key.
2) Press [EXECUTE] key.
Scanning is repeated at the speed corresponding to the scan
resolution (operation speed).
When [EXECUTE] key is pressed, the operation is terminated.
2
2-1
Purpose
Operation test/check
Function (Purpose)
Used to check the operations of the auto
document feed unit and the control circuit.
Section
RSPF/DSPF
Operation/Procedure
1) Select the operation mode and the speed with the touch panel
key.
2) Press [EXECUTE] key.
The RSPF repeats paper feed, transport, and paper exit oper-
ations at the speed corresponding to the scan resolution (oper-
ation speed).
When [EXECUTE] key is pressed, the operation is terminated.
[RSPF]
Item/Display Operation mode Default value
OC SCAN 300DPI 300DPI
(346.0mm/s)
300DPI
(346.0mm/s)
400DPI 400DPI
(259.5mm/s)
600DPI 600DPI
(173.0mm/s)
1200DPI 1200DPI
(86.5mm/s)
ǂǂǂ6,08/$7,21
ǂǂ12
&/26(
7(67
6&$11(5&+(&.


300DPI '3,'3,
2&6&$1 ˖
'3,
(;(&87(
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
6&$11(56(1625&+(&.





MHPS
Item/Display Operation mode Default value
OC SCAN 300DPI 300DPI
(346.0mm/s)
300DPI
(346.0mm/s)
400DPI 400DPI
(259.5mm/s)
600DPI 600DPI
(173.0mm/s)
1200DPI 1200DPI
(86.5mm/s)
Item/Display Operation mode Default value
(SINGLE) 300DPI 300DPI
(259.5mm/s)
300DPI
(259.5mm/s)
400DPI 400DPI
(259.5mm/s)
600DPI 600DPI
(173.0 mm/s)
(DOUBLE) 300DPI 300DPI
(259.5mm/s)
300DPI
(259.5mm/s)
400DPI 400DPI
(259.5mm/s)
600DPI 600DPI
(173.0 mm/s)
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
6&$11(5&+(&.



300DPI '3,'3,
2&6&$1 ˖
'3,
(;(&87(
