Sharp MX-5001N - B. Developing section

MX-5001N MAINTENANCE 8 – 9
B. Developing section
✕: Check (Clean, replace, or adjust according to necessity.) {: Clean S: Replace U: Adjust ✩: Lubricate
Color items
Monochrome items
No. Part name
When
calling
100
k
200
k
300
k
400
k
500
k
600
k
700
k
800
k
900
k
1000
k
1100
k
Remark/Refer to the
Parts Guide.
Block/Item No.
(Only the replacement
parts are described.)
1 Toner filter Supply - SSSSSSSSS S S(P/G No.: [22]-37)
2 DV blade - SSSSSSSSS S S(P/G No.: [22]-22)
3 DV side seal F/R - SSSSSSSSS S S(P/G No.: [23]-26, [23]-15)
4 Developer (Y) - SSSSSSSSS S S
Developer (M) - SSSSSSSSS S S
Developer (C) - SSSSSSSSS S S
5 Bias pin/Connector Mechanical
parts
- ✕✕✕✕✕✕✕✕✕ ✕ ✕
No. Part name
When
calling
150
k
300
k
450
k
600
k
750
k
900
k
1050
k
1200
k
1350
k
1500
k
1650
k
Remark/Refer to the
Parts Guide.
Block/Item No.
(Only the replacement
parts are described.)
1 Toner filter Supply - SSSSSSSSSSS(P/G No.: [22]-37)
2 DV blade - SSSSSSSSSSS(P/G No.: [22]-22)
3 DV side seal F/R - SSSSSSSSSSS(P/G No.: [23]-26, [23]-15)
4 Developer - SSSSSSSSSSS
5 Bias pin/Connector Mechanical
parts
-
✕✕✕✕✕✕✕✕✕✕✕
1
5
4
2
5
3
3
