Sharp MX-5001N - G. Filter section

MX-5001N MAINTENANCE 8 – 33
G. Filter section
✕: Check (Clean, replace, or adjust according to necessity.) {: Clean S: Replace U: Adjust ✩: Lubricate
1) Remove the ozone filter cover, and remove the ozone filter.
Maintenance: Replace filter at every 150K.
No. Part name
When
calling
150
k
300
k
450
k
600
k
750
k
900
k
1050
k
1200
k
1350
k
1500
k
1650
k
Remark/Refer to the
Parts Guide.
Block/Item No.
(Only the replacement
parts are described.)
1 Ozone filter Mechanical
parts
✕ SSSSSSSSSSS(P/G No.: [47]-40)
2 Left cabinet filter ✕ {{{{{{ {{{{{
1
1
1
2
1
: Oct. 24 2008
1
