MX-5001N SIMULATION 6 – 21
14
14--
Purpose
Clear/Cancel (Trouble etc.)
Function (Purpose)
Used to cancel excluding the self-diag U1/
U2/LCC/PF troubles.
Section
Operation/Procedure
1) Press [EXECUTE] key.
2) Press [YES] key to execute cancellation of the trouble.
15
15--
Purpose
Clear/Cancel (Trouble etc.)
Function (Purpose)
Used to cancel the self-diag "U6-09" (large
capacity paper feed tray) trouble.
Section
LCC
Operation/Procedure
1) Press [EXECUTE] key.
2) Press [YES] key to execute cancellation of the trouble.
16
16--
Purpose
Clear/Cancel (Trouble etc.)
Function (Purpose)
Used to cancel the self-diag "U2" trouble.
Section
MFP PWB / PCU PWB / SCU PWB
Operation/Procedure
1) Press [EXECUTE] key.
2) Press [YES] key to execute cancellation of the trouble.
17
17--
Purpose
Clear/Cancel (Trouble etc.)
Function (Purpose)
Used to cancel the self-diag "PF" trouble.
Section
Operation/Procedure
1) Press [EXECUTE] key.
2) Press [YES] key to execute cancellation of the trouble.
21
21-1
Purpose
Setting
Function (Purpose)
Used to set the maintenance cycle.
Section
Operation/Procedure
* Do not change the default setting value of the maintenance
counter on SIM21-1. The replacement timing of the fusing clean-
ing roller, the filter and PS paper dust removal cleaner may not
clarify.
1) Select a target item of setting with [↑] [↓] key on the touch
panel.
2) Enter the set value with 10-key.
3) Press [OK] key. (The set value is saved.)
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
7528%/(&$1&(//$7,2127+(5


$5(<28685("
<(6 12 (;(&87(
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
/&&7528%/(&$1&(//$7,21


$5(<28685("
<(6 12 (;(&87(
Item/Display Content Setting range
Default
value
A MAINTENANCE
COUNTER
(TOTAL)
Maintenance
counter
(Total)
0 : Default
1 - 300: 1K - 300K
999 : Free
150K
B MAINTENANCE
COUNTER
(COLOR)
Maintenance
counter
(Color)
0 : Default
1 - 300: 1K - 300K
999 : Free
100K
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
87528%/(&$1&(//$7,21


$5(<28685("
<(6 12 (;(&87(
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
3)7528%/(&$1&(//$7,21


$5(<28685("
<(6 12 (;(&87(
