MX-5001N SIMULATION 6 – 50
[50-sheet machine]
<Code descriptions>
<List of destination groups>
1
Item/Display Content
Setting
range
Default value
Destination
linkage
(NOTE)
Group 1 Group 2 Group 3
SW-A SW-B SW-A SW-B SW-A SW-B
A HL_UM PLAIN PAPER BW DUP Black-White plain paper duplex
TH_UM set value
70 - 230 185 190 185 190 185 190 {
B HL_LM PLAIN PAPER BW DUP Black-White plain paper duplex
TH_LM set value
30 - 200 100 100 100 100 100 100 {
C HL_E PLAIN PAPER BW DUP Black-White plain paper duplex TH_E
set value
70 - 230 220 220 220 220 220 220 {
D PLAIN PAPER BW DUP APP CNT Black-White plain paper duplex
applying number of sheets
0 - 60 40 40 40 40 40 40 {
E HL_UM PLAIN PAPER CL DUP Color plain paper duplex TH_UM set
value
70 - 230 185 190 185 190 185 190 {
F HL_LM PLAIN PAPER CL DUP Color plain paper duplex TH_LM set
value
30 - 200 100 100 100 100 100 100 {
G HL_E PLAIN PAPER CL DUP Color plain paper duplex TH_E set
value
70 - 230 220 220 220 220 220 220 {
H PLAIN PAPER CL DUP APP CNT Color plain paper duplex applying
number of sheets
0 - 60 40 40 40 40 40 40 {
I HL_UM HEAVY PAPER BW DUP Black-White heavy paper duplex
TH_UM set value
70 - 230 185 185 185 185 185 185 –
J HL_LM HEAVY PAPER BW DUP Black-White heavy paper duplex
TH_LM set value
30 - 200 120 120 120 120 120 120 –
K HL_E HEAVY PAPER BW DUP Black-White heavy paper duplex TH_E
set value
70 - 230 220 220 220 220 220 220 –
L HEAVY PAPER BW DUP APP CNT Black-White heavy paper duplex
applying number of sheets
0 - 60111111 –
M HL_UM HEAVY PAPER CL DUP Color heavy paper duplex TH_UM set
value
70 - 230 185 185 185 185 185 185 –
N HL_LM HEAVY PAPER CL DUP Color heavy paper duplex TH_LM set
value
30 - 200 120 120 120 120 120 120 –
O HL_E HEAVY PAPER CL DUP Color heavy paper duplex TH_E set
value
70 - 230 220 220 220 220 220 220 –
P HEAVY PAPER CL DUP APP CNT Color heavy paper duplex applying
number of sheets
0 - 60111111 –
TH_UM Fusing upper thermister main center HL_UM Heater lamp upper main
TH_LM Fusing lower thermister main HL_LM Heater lamp lower main
TH_E Fusing thermister external HL_E Heater lamp external
Group 1 Japan China AB_B
Group 2 U.S.A. Canada Inch
Group 3 Europe U.K. AUS AB_A
SW-A Setting value when plain paper is selected in the system setting/device setting/fusing control setting.
SW-B Set value when heavy paper is selected in the system setting/device setting/fusing control setting.
The set value displayed in this simulation differs depending on plain paper or heavy paper which is selected in the system setting/device setting/fusing
control setting.
(Example) When plain paper is selected in the system setting/device setting/fusing control setting, the value of SW-A is displayed.
NOTE: When the destination is changed with SIM26-6 after changing this set value, the set values of the destination link items are reset to the default.
