MX-5001N SIMULATION 6 – 52
* Item L: 1 Count = 1s Change
Correction value for the other items: 1 count for 1°C change
* Item D, F: When B5 size, correction of "-5" is made for item D and item F.
* Item G, I: When B5 size, correction of "-5" is made for item G and item I.
[50-sheet machine]
AB HL_LM E-STAR LL Correction value for preheating TH_LM set value under LL
environment
1 - 99 55 55 55 –
AC HL UM HEAVY2 CL LL Correction value for heavy paper 2 TH_UM set value under
LL environment
1 - 99 55 55 55 –
AD HL LM HEAVY2 CL LL Correction value for heavy paper 2 TH_LM set value under
LL environment
1 - 99 55 55 55 –
AE HL E HEAVY2 CL LL Correction value for heavy paper 2 TH_E set value under
LL environment
1 - 99 50 50 50 –
AF HL_UM WARMUP_120L LL Correction value for TH_UM set value in WarmUp at 120°C
or below under LL environment
1 - 99 55 55 55 –
AG HL_LM WARMUP_120L LL Correction value for TH_LM set value in WarmUp at 120°C
or below under LL environment
1 - 99 55 55 55 –
AH HL_E WARMUP_120L LL Correction value for TH_E set value in WarmUp at 120°C
or below under LL environment
1 - 99 50 50 50 –
AI LO_WARMUP_TIME_LL Correction value for AF-AH applying time (timer from
Ready complete) under LL environment
1 - 99 50 50 50 –
AJ HL_UM WARMUP_120H LL Correction value for TH_UM set value in WarmUp at 120°C
or above under LL environment
1 - 99 55 55 55 –
AK HL_LM WARMUP_120H LL Correction value for TH_LM set value in WarmUp at 120°C
or above under LL environment
1 - 99 55 55 55 –
AL HL_E WARMUP_120H LL Correction value for TH_E set value in WarmUp at 120°C
or above under LL environment
1 - 99 50 50 50 –
AM HI_WU_TIME_LL Correction value for AJ-AL applying time (timer from Ready
complete) under LL environment
1 - 99 50 50 50 –
AN HI_WU_FM_ON_TMP_LL Correction value for FM prior rotation start TH_UM in
WarmUp at alpha °C or above under LL environment
1 - 99 45 45 45 –
AO HI_WU_END_TIME_LL Correction value for WarmUp completion time in WarmUp
at alpha °C or above under LL environment
1 - 99 50 50 50 –
AP HI_WU_JOB_SET_TMP_LL Correction value for Job Enable TH_UM temperature in at
alpha °C or above under LL environment
1 - 99 55 55 55 –
AQ HI_WARMUP_BORDER_LL Correction value for the threshold value alpha applying
SIM43-1-AN - AP under LL environment
1 - 99 50 50 50 –
AR LO_WU_JOB_SET_TMP_LL Correction value for Job Enable TH_UM temperature in at
alpha °C or below under LL environment
1 - 99 55 55 55 –
AS ROT_TIME_AFTER_JOB_LL Correction value for the after rotation time when completing
a job under LL environment
1 - 99 50 50 50 –
Item/Display Content
Setting
range
Default value Destination
linkage
(NOTE)
Group 1 Group 2 Group 3
1
Item/Display Content
Setting
range
Default value Destination
linkage
(NOTE)
Group 1 Group 2 Group 3
A HL_UM READY LL Correction value for TH_UM set value in Ready standby
under LL environment
1 - 99 55 55 55 {
B HL_LM READY LL Correction value for TH_LM set value in Ready standby
under LL environment
1 - 99 55 55 55 {
C HL_E READY LL Correction value for TH_E set value in Ready standby
under LL environment
1 - 99 55 55 55 {
D HL_UM PLAIN BW LL Correction value for Black-White plain paper TH_UM set
value under LL environment
1 - 99 55 55 55 {
E HL_LM PLAIN BW LL Correction value for Black-White plain paper TH_LM set
value under LL environment
1 - 99 55 55 55 {
F HL_E PLAIN BW LL Correction value for Black-White plain paper TH_E set
value under LL environment
1 - 99 50 50 50 {
G HL_UM PLAIN CL LL Correction value for Color plain paper TH_UM set value
under LL environment
1 - 99 55 55 55 {
H HL_LM PLAIN CL LL Correction value for Color plain paper TH_LM set value
under LL environment
1 - 99 55 55 55 {
I HL_E PLAIN CL LL Correction value for Color plain paper TH_E set value
under LL environment
1 - 99 50 50 50 {
J WARMUP FUMON HL_E T LL Correction value for fusing motor pre-rotation start TH_E
set value under LL environment
1 - 99 45 45 45 –
K WARMUP FUMOFF T LL Fusing motor prior rotation completion time under LL
environment
1 - 99 50 50 50 –
L WARMUP END TIME LL Correction value for warm-up complete time under LL
environment
1 - 99 80 80 80 –
: Oct. 24 2008
