MX-5001N SIMULATION 6 – 67
44-12
Purpose
Operation data display
Function (Purpose)
Used to display the operation data of the
high density process control and the image
density sensor (registration sensor).
Section
Image process (Photoconductor/Develop-
ing)
Operation/Procedure
Select a display mode with [TARGET] [PATCH] keys.
44-13
Purpose
Adjustment/Setup
Function (Purpose)
Used to perform the color image sensor
(image registration sensor F) calibration.
Section
Operation/Procedure
1) Attach the calibration jig.
2) Press [EXECUTE] key.
Calibration is performed, and the data are displayed.
44-14
Purpose
Operation data display
Function (Purpose)
Used to display the output level of the tem-
perature and humidity sensor.
Section
Process (OPC drum, development)/Fusing/
LSU
Operation/Procedure
The output levels of the fusing temperature sensor, the machine
temperature sensor, and the humidity sensor are displayed.
Mode Item/Display Content
Display
range
Default
value
TARGET
(1 page)
CARB DATA Calibration plate
detection level
0 - 255 108
SEAL ADJ
DATA
Jig patch seal
detection level when
executing SIM 44-13
1 - 255 108
ADK_SL (K) Development
characteristics
gradient coefficient
(High density process
control operation)
-9.99 -
9.99
0
ADK_INT(K) Development
characteristics
intercept level (High
density process
control operation 0V)
-999.9 -
999.9
0
TARGET (K) High density process
control target density
level (K)
0.00 -
255.00
0
TARGET
(C/M/Y)
High density process
control target density
level (C/M/Y)
0.00 -
255.00
0
PATCH
1-5
(Page 1-2)
n-1 High density process
control nth time patch
density level 1 (n=1-
5)
0 - 255 0
n-2 Patch data nth time
patch 2 (n=1-5)
0 - 255 0
n-3 Patch data nth time
patch 3 (n=1-5)
0 - 255 0
n-4 Patch data nth time
patch 4 (n=1-5)
• BK only
0 - 255 0
n-5 Patch data nth time
patch 5 (n=1-5)
• BK only
0 - 255 0
PATCH
6-10
(Page 1-2)
n-1 Patch data nth time
patch 1 (n=6-10)
0 - 255 0
n-2 Patch data nth time
patch 2 (n=6-10)
0 - 255 0
n-3 Patch data nth time
patch 3 (n=6-10)
0 - 255 0
n-4 Patch data nth time
patch 4 (n=6-10)
• BK only
0 - 255 0
n-5 Patch data nth time
patch 5 (n=6-10)
• BK only
0 - 255 0
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
3$7&+7$5*(7'$7$',63/$<



&$5%'$7$
6($/$'-'$7$
$'.B6/.
$'.B,17.
7$5*(7.
7$5*(7&
7$5*(70
7$5*(7<
3$7&+7$5*(7 3$7&+
Item/Display Content
Setting
range
Default
value
A PCS_CL CARB OUT Calibration plate
sensor value
1 - 255 108
B PCS_CL LED ADJ Color sensor light
emitting quantity
adjustment value
1 - 255 21
Item/Display Content Display range
TH_UM Fusing upper thermister main
detection temperature (°C)
Difference AD input value (AD
value)
Temperature:
0 - 255°C(±1°C)
AD value: 0-1023
TH_UM_AD1 Fusing upper thermister main
compensation temperature (°C)
AD value (AD value)
Temperature:
0.0-255.0°C
(±0.2°C)
AD value: 0-1023
TH_UM_AD2 Fusing upper thermister main
detection sensor AD value (AD
value)
AD value:0-1023
TH_LM Fusing lower thermister main A/D
value (temperature °C)
Temperature:
0 - 255°C(±1°C)
AD value: 0-1023
TH_E Fusing external thermistor A/D
value (temperature °C)
Temperature:
0 - 255°C(±1°C)
AD value: 0-1023
TEMPRATURE Temperature thermister Temperature:
-40.0 - 60.0°C
(±0.1°C)
AD value: 0-1023
HUMIDITY Humidity sensor Humidity:
5.0-90.0% (±0.1%),
AD value: 0-1023
TH1_LSU LSU thermister 1 A/D value
(temperature °C)
Temperature:
5.0-60.0°C
(±0.1°C)
AD value: 0-255
