Sharp MX-5001N - Page 217

MX-5001N SIMULATION 6 – 70
44-25
Purpose
Setting
Function (Purpose)
Used to set the calculating conditions of the
correction value for the half tone process
control.
Section
Process
Operation/Procedure
1) Select a target adjustment color with [K] [C] [M] [Y] key.
2) Select a target adjustment density level with [↑] [↓] key on the
touch panel.
3) Enter the set value with 10-key.
4) Press [OK] key.
NOTE: Set the items to the default values unless a change is spe-
cially required.
44-26
Purpose
Adjustment/Setup
Function (Purpose)
Used to execute the half tone process con-
trol compulsory.
Section
Process
Operation/Procedure
Press [EXECUTE] key.
The half tone process control is performed and the operation data
are displayed.
44-27
Purpose
Data clear
Function (Purpose)
Used to clear the correction data of the half
tone process control.
Section
Process
Operation/Procedure
1) Press [EXECUTE] key.
2) Press [YES] key.
The correction data of the half tone process control are
cleared.
For printer [PRINTER_S_VALUE] Printer half tone process
control correction value
[PRINTER_BASE_DITHER
_VALUE]
Printer half tone process
control reference dither
value
[PRINTER_AUTO_HT
_VALUE]
Printer auto density
adjustment correction value
Previous
correction
value
[BEFORE S_VALUE] Previous half tone process
control value
Item/Display Content
Setting
range
Default value
KCMY
A LOW FIELD
LOWER LIMIT
Low density
approximate
expression data
lower limit value
0 - 255 98 2
B LOW FIELD
UPPER LIMIT
Low density
approximate
expression data
upper limit value
0 - 255 60 40
C MID FIELD
LOWER LIMIT
Medium density
approximate
expression data
lower limit value
0 - 255 90 15
D MID FIELD
UPPER LIMIT
Medium density
approximate
expression data
upper limit value
0 - 255 6 144
E HIGHLIGHT
POINT
Reference point of
the highlight
correction amount
1 - 8 7 7
Category Item/Display Content
ǂǂǂ6,08/$7,21
ǂǂ12
&/26(
7(67
+$/)721(352&215(68/7',63/$<



1(;7
>(;/2:@$%
>/2:@$%&
>&211(&7@$%
>0,'@$%&
>+,*+@$%
>&211(&732,17@
. & 0 <
COMPLETE Normal complete
ERROR COLOR SENSOR
ADJUSTMENT
Color image density sensor sensitivity
adjustment error
ERROR BLACK SENSOR
ADJUSTMENT
Black image density sensor sensitivity
adjustment error
[YMCK] High density process control error [YMCK]
error
OTHER Other errors
ǂǂǂ6,08/$7,21
ǂǂ12
&/26(
7(67
+$/)721(352&21,1,7,$/9$/8(',63/$<



$˖
˷ 
˹
˖/2:),(/'/2:(5/,0,7
$˖

˖/2:),(/'833(5/,0,7
%˖

˖0,'),(/'/2:(5/,0,7
&˖

˖0,'),(/'833(5/,0,7
'˖

˖+,*+/,*+732,17
(˖

2.
. & 0 <
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
+$/)721('(16,7<&255(&7(;(&87,21


(;(&87(
728&+>(;(&87(@7+(1(;(&87,2167$57
