MX-5001N SIMULATION 6 – 91
46-61
Purpose
Adjustment/Setup
Function (Purpose)
Used to adjust the area separation recogni-
tion level.
Section
Operation/Procedure
1) Select a target adjustment item with [↑] [↓] key on the touch
panel.
2) Enter the adjustment value using the 10-key.
3) Press [OK] key.
NOTE: This must be set to the default unless any change is spe-
cially required.
When the adjustment value is set to a value greatly different from
the default value, image quality trouble may occur for some docu-
ments.
46-62
Purpose
Adjustment/Setup
Function (Purpose)
Used to set the operating conditions of the
ACS, the area separation, the background
image process, and the auto exposure
mode.
Section
Operation/Procedure
1) Select a target adjustment item with [↑] [↓] key on the touch
panel.
2) Enter the adjustment value using the 10-key.
3) Press [OK] key.
NOTE: This must be set to the default unless any change is spe-
cially required.
When the adjustment value is set to a value greatly different from
the default value, image quality trouble may occur for some docu-
ments.
Item/Display Content
Setting
range
Default
value
A SEGMENT:
SWITCH [TXT ON
SCR]
Detection ON/OFF:
Text on dot
0 - 1 0
B SEGMENT:
SWITCH [LINE SCR]
etection ON/OFF:
line screen
0 - 1 0
C SEGMENT:
SWITCH [SMALL
SCR]
Detection ON/OFF:
Dot in a small area
0 - 1 0
D SEGMENT:
ADJUST [BK TXT 1]
Detection level
adjustment:
Black text 1
1 - 5 3
E SEGMENT:
ADJUST [CL TXT 1]
Detection level
adjustment:
Color text 1
1 - 5 3
F SEGMENT:
ADJUST [BK TXT 2 ,
CL TXT 2]
Detection level
adjustment:
Black text 2, Color
text 2
1 - 5 3
G SEGMENT:
ADJUST [BK/CL]
Detection level
adjustment:
Chroma/Achroma
judgment
1 - 5 3
H SEGMENT:
ADJUST [TXT ON
BG]
Detection level
adjustment:
Text on background
1 - 5 3
I SEGMENT:
ADJUST [SCR]
Detection level
adjustment:
Dot
1 - 5 3
ǂǂǂ6,08/$7,21
ǂǂ12
&/26(
7(67
6(*0(17/(9(/$'-8670(17



$˖
˷
˹
˖6(*0(176:,7&+
>7;7216&5@
$˖

˖6(*0(176:,7&+
>/,1(6&5@
%˖

˖6(*0(176:,7&+
>60$//6&5@
&˖

˖6(*0(17$'-867
>%.7;7@
'˖

˖6(*0(17$'-867>%.7;7
&/7;7@
)˖

˖6(*0(17$'-867
>&/7;7@
(˖

˖6(*0(17$'-867
>%.&/@
*˖

˖6(*0(17$'-867
>7;721%*@
+˖

˖6(*0(17$'-867
>6&5@
,˖

2.
Item/Display Content
Setting
range
Default
value
A SW_ACS ACS judgment
reference area
adjustment
0 - 1 1
B TEXT_IMAGE SIM display item:
Text/Image judgment
priority level select
0 - 6 3
C TEXT_BLANK SIM display item:
Text/Blank judgment
priority level select
0 - 6 4
D HT_LV Dot area judgment
threshold value
adjustment
0 - 6 1
E AE_AREA_LV SIM display item:
Color AE judgment
target area adjustment
value
0 - 6 3
F AE_LV_CC AE background
detection division result
adjustment:
For color copy
0 - 8 4
G AE_LV_MC AE background
detection division result
adjustment:
For monochrome copy
0 - 8 4
H AE_LV_CS AE background
detection division result
adjustment:
For color scan
0 - 8 4
I AE_LV_MS AE background
detection division result
adjustment:
For monochrome scan
0 - 8 4
J AE_JUDGE
_LV_L_U
Color AE background
density threshold value
adjustment value
(lower limit)
0 - 4 0
K AE_JUDGE
LV_L_O
Color AE background
density threshold value
adjustment value
(upper limit)
0 - 10 0
L AE_JUDGE_
LV_C
Color AE background
detection level
adjustment (chroma)
0 - 10 5
MAE
_ONOFF
_CC
ON AE mode ON/
OFF switch :
For color copy
ON 0 - 1 0 0 (ON)
OFF OFF 1
NAE
_ONOFF
_MC
ON AE mode ON/
OFF switch :
For mono-
chrome copy
ON 0 - 1 0 0 (ON)
OFF OFF 1
OAE
_ONOFF
_CS
ON AE mode ON/
OFF switch :
For color scan
ON 0 - 1 0 0 (ON)
OFF OFF 1
PAE
_ONOFF
_MS
ON AE mode ON/
OFF switch :
For mono-
chrome copy
ON 0 - 1 0 0 (ON)
OFF OFF 1
Q BLANK_JUDGE_
LV_L
Blank judgment level
adjustment (value)
0 - 10 0
R BLANK_JUDGE_
LV_C
Blank judgment level
adjustment (chroma)
0 - 10 0
