MX-5001N SIMULATION 6 – 93
46-90
Purpose
Adjustment/Setup
Function (Purpose)
Used to adjust the high compression PDF
ASIC.
(Do not change default value in the field)
Section
Operation/Procedure
1) Select a target adjustment mode with [TEXT], [COLOR] and
[BG LAYER] keys.
2) Select a target adjustment item with [↑] [↓] key.
3) Enter the set value with 10-key.
4) Press [OK] key.
The set value is saved.
48
48-1
Purpose
Adjustment
Function (Purpose)
Used to adjust the scan image magnifica-
tion ratio (in the main scanning direction
and the sub scanning direction).
Section
Operation/Procedure
1) Select a target adjustment item with [↑] [↓] key on the touch
panel.
2) Enter the set value with 10-key.
3) Press [OK] key.
The set value is saved.
When the adjustment value is increased, the image magnification
ratio is increased.
A change of "1" in the adjustment value of item A, C, or E corre-
sponds to a change of about 0.02% in the copy magnification ratio.
A change of "1" in the adjustment value of item B, D, or F corre-
sponds to a change of about 0.1% in the copy magnification ratio.
[RSPF]
[DSPF]
Item Button Display Content
Setting
range
Default
value
A TEXT GLYPH
SENSITIVITY
Text handling
selection
0 - 2 0
B BG SW FOR
FINDLINES
Line handling
selection
0 - 1 0
CHOR
FINDLINES SW
Line detection
SW (H)
0 - 2 0
D VERT
FINDLINES SW
Line detection
SW (V)
0 - 2 0
E FGCOLOR
INDEXING SEL
Te x t c o lor
number
adjustment SW
0 - 3 0
F FGCOLOR
INDEXING ADJ
Te x t c o lor
adjustment
0 - 4 2
A COLOR LUMINANCE
ADJUSTMENT
Luminance
adjustment
0 - 4 2
B CHROMA
INTENT
Chroma
selection
0 - 2 1
ABG
LAYER
BG LAYER
INTENT 1
Speed priority
setting
0 - 2 1
B BG LAYER
INTENT 2
Image quality
priority setting
0 - 2 1
ǂǂǂ6,08/$7,21
ǂǂ12
&/26(
7(67
(1*,1($872$'-8670(176(59,&(


(;(&87(
35(66>(;(&87(@72352&21(;(&87,21$1'35,177+(7(673$7&+

3/($6(86(63(&,),('7<3(2)$25h6,=(3$3(5
)257+,6$'-8670(17
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
&203$&73')6(77,1*6



$˖
˷ ˹
˖*/<3+6(16,7,9,7<
$˖
˖%*6:)25),1'/,1(6
%˖
˖+25),1'/,1(66:
&˖
˖9(57),1'/,1(66:
㪛䋺㩷㩷㩷㩷㩷㩷㪇
˖)*&2/25,1'(;,1*$'-
)˖
˖)*&2/25,1'(;,1*6(/
(˖
2.
&2/257(;7 %*/$<(5
Item/Display Content
Setting
range
Default
value
A CCD (MAIN) SCAN main scanning
magnification ratio
adjustment (CCD)
1 - 99 50
B CCD (SUB) SCAN sub scanning
magnification ratio
adjustment (CCD)
1 - 99 50
C SPF (MAIN) RSPF document front
surface magnification ratio
(Main scan)
1 - 99 50
D SPF (SUB) RSPF document front
surface magnification ratio
(Sub scan)
1 - 99 50
E SPFB (MAIN) RSPF document back
surface magnification ratio
(Main scan)
1 - 99 50
F SPFB (SUB) RSPF document back
surface magnification ratio
(Sub scan)
1 - 99 50
Item/Display Content
Setting
range
Default
value
A CCD(MAIN) SCAN main scanning
magnification ratio
adjustment (CCD)
1 - 99 50
B CCD(SUB) SCAN sub scanning
magnification ratio
adjustment (CCD)
1 - 99 50
C SPF(MAIN) DSPF document front
surface magnification ratio
(Main scan)
1 - 99 50
D SPF(SUB) DSPF document front
surface magnification ratio
(Sub scan)
1 - 99 50
E SPFB(MAIN) DSPF document back
surface magnification ratio
(Main scan)
1 - 99 50
