MX-5001N SIMULATION 6 – 110
Sampling
status
check (7)
VALID_LINE
_MAX_M_R_U
Adjacent data
linearity
difference in
the effective
line after
removing the
sampling noise
Line No. at
MAX Main
scanning R
(Rising)
1-16(±1unit) 50-22
VALID_LINE
_MAX_M_R_D
Adjacent data
linearity
difference in
the effective
line after
removing the
sampling noise
Line No. at
MAX Main
scanning R
(Falling)
1-16(±1unit) 50-22
VALID_LINE
_MIN_S_F_U
Adjacent data
linearity
difference in
the effective
line after
removing the
sampling noise
Line No. at MIN
Sub scanning
F (Rising)
1-17(±1unit) 50-22
VALID_LINE
_MIN_S_F_D
Adjacent data
linearity
difference in
the effective
line after
removing the
sampling noise
Line No. at MIN
Sub scanning
F (Falling)
1-17(±1unit) 50-22
VALID_LINE
_MIN_S_R_U
Adjacent data
linearity
difference in
the effective
line after
removing the
sampling noise
Line No. at MIN
Sub scanning
R (Rising)
1-17(±1unit) 50-22
VALID_LINE
_MIN_S_R_D
Adjacent data
linearity
difference in
the effective
line after
removing the
sampling noise
Line No. at MIN
Sub scanning
R (Falling)
1-17(±1unit) 50-22
VALID_LINE
_MIN_M_F_U
Adjacent data
linearity
difference in
the effective
line after
removing the
sampling noise
Line No. at MIN
Main scanning
F (Rising)
1-16(±1unit) 50-22
Item
classific
ation
Display Item content
Setting
range
Related
SIM
Sampling
status
check (7)
VALID_LINE
_MIN_M_F_D
Adjacent data
linearity
difference in
the effective
line after
removing the
sampling noise
Line No. at MIN
Main scanning
F (Falling)
1-16(±1unit) 50-22
VALID_LINE
_MIN_M_R_U
Adjacent data
linearity
difference in
the effective
line after
removing the
sampling noise
Line No. at MIN
Main scanning
R (Rising)
1-16(±1unit) 50-22
VALID_LINE
_MIN_M_R_D
Adjacent data
linearity
difference in
the effective
line after
removing the
sampling noise
Line No. at MIN
Main scanning
R (Falling)
1-16(±1unit) 50-22
Tempera-
ture
correc-
tion value
check
TEMP_ADJ_M1 Temperature
correction
value in the
previous print
Main scan
writing
-99.9-99.9
(±0.1unit)
-
TEMP_ADJ_M2 Temperature
correction
value in the
previous print
Main scan
magnification
ratio
-99.9-99.9
(±0.1unit)
-
TEMP_ADJ
_SUB
Temperature
correction
value in the
previous print
Sub scan
-99.9-99.9
(±0.1unit)
-
Tempera-
ture
check
TEMP_BACK
_TH1
Temperature in
the previous
print
(Thermister 1)
5.0-60.0
(±0.1°C)
-
TEMP_BACK
_TH2
Temperature in
the previous
print
(Thermister 2)
5.0-60.0
(±0.1°C)
-
TEMP_TH1_F
_HISTORY
Reference
temperature
(Thermister 1)
F
5.0-60.0
(±0.1°C)
50-20,
21, 22
TEMP_TH1_R
_HISTORY
Reference
temperature
(Thermister 1)
R
5.0-60.0
(±0.1°C)
50-20,
21, 22
TEMP_TH2_F
_HISTORY
Reference
temperature
(Thermister 2)
F
5.0-60.0
(±0.1°C)
50-20,
21, 22
TEMP_TH2_R_
HISTORY
Reference
temperature
(Thermister 2)
R
5.0-60.0
(±0.1°C)
50-20,
21, 22
Error
record
status
check
ERROR
HISTORY
Error record
status check
-50-22
Item
classific
ation
Display Item content
Setting
range
Related
SIM
