MX-5001N SIMULATION 6 – 117
When the above operation is nor performed normally, "ERROR" is
displayed and. When the above operation is completed normally,
"COMPLETE" is displayed.
53-7
Purpose
Adjustment/Setup
Function (Purpose)
Used to adjust the RSPF/DSPF document
size width sensor.
Section
Operation/Procedure
1) Select an adjustment target item with [↑] [↓] key on the touch
panel.
2) Enter the set value with 10-key.
3) Press [OK] key. (The set value is saved.)
[RSPF]
[DSPF]
53-8
Purpose
Adjustment
Function (Purpose)
Used to adjust the document lead edge ref-
erence and the RSPF/DSPF mode docu-
ment scan position.
Section
Operation/Procedure
Select an adjustment item with [AUTO] [MANUAL] key.
<AUTO: Document lead edge reference (RRCA) adjustment>(Auto
adjustment)
1) Set a sheet of black paper of A4 or 11"x 8.5" on the document
table.
2) Press [EXCUTE] key. (The adjustment is performed and the
adjustment value is saved.)
<MANUAL: RSPF/DSPF mode document scan position adjust-
ment>
1) Enter the set value with 10-key.
2) Press [OK] key. (The set value is saved.)
• When the adjustment value is increased, the scanner stop posi-
tion in the RSPF/DSPF mode is shifted to the right.
• When the adjustment value is changed by 1, the position is
shifted by 0.1mm.
1 TRAYVOLMAX Tray size volume maximum value
2 TRAYVOLA4R Tray volume A4R size adjustment value
3 TRAYVOLA5R Tray volume A5R size adjustment value
4 TRAYVOLMIN Tray size volume minimum value
Item/Display
Setting
range
Default
value
A AD_MAX Max. width position 0 - 1023 72
B AD_P1 A4R width position 0 - 1023 499
C AD_P2 A5R width position 0 - 1023 805
D AD_MIN Min. width position 0 - 1023 955
Item/Display
Setting
range
Default
value
A AD_MAX Max. width position 0 - 1023 66
B AD_P1 A4R width position 0 - 1023 438
C AD_P2 A5R width position 0 - 1023 699
D AD_MIN Min. width position 0 - 1023 893
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
63)75$<$'-8670(17


(;(&87(
75$<92/0$;75$<$'-8670(17
35(66>(;(&87(@7267$57
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
63)75<$'-8670(170$18$/



$˖
˷˹
˖$'B0$;
$˖
$'B3
%˖
$'B3
&˖
$'B0,1
'˖
ǂ
2.
Item/Display Content
Setting
range
Default
value
MEASUREMENT
DISTANCE
Document lead edge
measurement distance
0-255
(0.1mm unit)
-
RRCA Document lead edge
reference position
0 - 99 50
Item/Display Content
Setting
range
Default
value
A ADJUST
VALUE
RSPF/DSPF mode document
scan position adjustment
(Scanner stop position
adjustment)
1 - 99 10
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
63)6&$11,1*326,7,21$'-8670(17


$872 0$18$/



