Sharp MX-5001N - Page 269

MX-5001N SIMULATION 6 – 122
PR600/
FAX
A LASER POWER MIDDLE (K1) Used to set the laser power (Middle speed/K1) 0 - 255 133 165 ✕
B LASER POWER MIDDLE (K2) Used to set the laser power (Middle speed/K2) 0 - 255 133
165 ✕
C LASER POWER MIDDLE (C1) Used to set the laser power (Middle speed/C1) 0 - 255 146
165 ✕
D LASER POWER MIDDLE (C2) Used to set the laser power (Middle speed/C2) 0 - 255 146
165 ✕
E LASER POWER MIDDLE (M1) Used to set the laser power (Middle speed/M1) 0 - 255 146
165 ✕
F LASER POWER MIDDLE (M2) Used to set the laser power (Middle speed/M2) 0 - 255 146
165 ✕
G LASER POWER MIDDLE (Y1) Used to set the laser power (Middle speed/Y1) 0 - 255 146
165 ✕
H LASER POWER MIDDLE (Y2) Used to set the laser power (Middle speed/Y2) 0 - 255 146
165 ✕
I LASER POWER LOW (K1) Used to set the laser power (Low speed/K1) 0 - 255 142
142 ✕
J LASER POWER LOW (K2) Used to set the laser power (Low speed/K2) 0 - 255 142
142 ✕
K LASER POWER LOW (C1) Used to set the laser power (Low speed/C1) 0 - 255 142
142 ✕
L LASER POWER LOW (C2) Used to set the laser power (Low speed/C2) 0 - 255 142
142 ✕
M LASER POWER LOW (M1) Used to set the laser power (Low speed/M1) 0 - 255 142
142 ✕
N LASER POWER LOW (M2) Used to set the laser power (Low speed/M2) 0 - 255 142
142 ✕
O LASER POWER LOW (Y1) Used to set the laser power (Low speed/Y1) 0 - 255 142
142 ✕
P LASER POWER LOW (Y2) Used to set the laser power (Low speed/Y2) 0 - 255 142
142 ✕
Q LASER POWER MIDDLE (BW1) Used to set the laser power (Middle speed/BW1) 0 - 255 133
165 ✕
R LASER POWER MIDDLE (BW2) Used to set the laser power (Middle speed/BW2) 0 - 255 133
165 ✕
S LASER POWER LOW (BW1) Used to set the laser power (Low speed/BW1) 0 - 255 142
142 ✕
T LASER POWER LOW (BW2) Used to set the laser power (Low speed/BW2) 0 - 255 142
142 ✕
U LASER DUTY MIDDLE (K) Laser DUTY select middle speed (K) 0 - 255 0
0 {
V LASER DUTY MIDDLE (C) Laser DUTY select middle speed (C) 0 - 255 0
0 {
W LASER DUTY MIDDLE (M) Laser DUTY select middle speed (M) 0 - 255 0
0 {
X LASER DUTY MIDDLE (Y) Laser DUTY select middle speed (Y) 0 - 255 0
0 {
Y LASER DUTY LOW (K) Laser DUTY select low speed (K) 0 - 255 0
0 {
Z LASER DUTY LOW (C) Laser DUTY select low speed (C) 0 - 255 0
0 {
AA LASER DUTY LOW (M) Laser DUTY select low speed (M) 0 - 255 0
0 {
AB LASER DUTY LOW (Y) Laser DUTY select low speed (Y) 0 - 255 0
0 {
AC LASER DUTY MIDDLE (BW) Laser DUTY select middle speed (BW) 0 - 255 0
0 {
AD LASER DUTY LOW (BW) Laser DUTY select low speed (BW) 0 - 255 0
0 {
PR1200 A LASER POWER MIDDLE (K1) Used to set the laser power (Middle speed/K1) 0 - 255 133
165 ✕
B LASER POWER MIDDLE (K2) Used to set the laser power (Middle speed/K2) 0 - 255 133
165 ✕
C LASER POWER MIDDLE (C1) Used to set the laser power (Middle speed/C1) 0 - 255 146
165 ✕
D LASER POWER MIDDLE (C2) Used to set the laser power (Middle speed/C2) 0 - 255 146
165 ✕
E LASER POWER MIDDLE (M1) Used to set the laser power (Middle speed/M1) 0 - 255 146
165 ✕
F LASER POWER MIDDLE (M2) Used to set the laser power (Middle speed/M2) 0 - 255 146
165 ✕
G LASER POWER MIDDLE (Y1) Used to set the laser power (Middle speed/Y1) 0 - 255 146
165 ✕
H LASER POWER MIDDLE (Y2) Used to set the laser power (Middle speed/Y2) 0 - 255 146
165 ✕
I LASER POWER LOW (K1) Used to set the laser power (Low speed/K1) 0 - 255 142
142 ✕
J LASER POWER LOW (K2) Used to set the laser power (Low speed/K2) 0 - 255 142
142 ✕
K LASER POWER LOW (C1) Used to set the laser power (Low speed/C1) 0 - 255 142
142 ✕
L LASER POWER LOW (C2) Used to set the laser power (Low speed/C2) 0 - 255 142
142 ✕
M LASER POWER LOW (M1) Used to set the laser power (Low speed/M1) 0 - 255 142
142 ✕
N LASER POWER LOW (M2) Used to set the laser power (Low speed/M2) 0 - 255 142
142 ✕
O LASER POWER LOW (Y1) Used to set the laser power (Low speed/Y1) 0 - 255 142
142 ✕
P LASER POWER LOW (Y2) Used to set the laser power (Low speed/Y2) 0 - 255 142
142 ✕
Q LASER POWER MIDDLE (BW1) Used to set the laser power (Middle speed/BW1) 0 - 255 133
165 ✕
R LASER POWER MIDDLE (BW2) Used to set the laser power (Middle speed/BW2) 0 - 255 133
165 ✕
S LASER POWER LOW (BW1) Used to set the laser power (Low speed/BW1) 0 - 255 142
142 ✕
T LASER POWER LOW (BW2) Used to set the laser power (Low speed/BW2) 0 - 255 142
142 ✕
U LASER DUTY MIDDLE (K) Laser DUTY select middle speed (K) 0 - 255 0
0 ✕
V LASER DUTY MIDDLE (C) Laser DUTY select middle speed (C) 0 - 255 0
0 ✕
W LASER DUTY MIDDLE (M) Laser DUTY select middle speed (M) 0 - 255 0
0 ✕
X LASER DUTY MIDDLE (Y) Laser DUTY select middle speed (Y) 0 - 255 0
0 ✕
Y LASER DUTY LOW (K) Laser DUTY select low speed (K) 0 - 255 0
0 ✕
Z LASER DUTY LOW (C) Laser DUTY select low speed (C) 0 - 255 0
0 ✕
AA LASER DUTY LOW (M) Laser DUTY select low speed (M) 0 - 255 0
0 ✕
AB LASER DUTY LOW (Y) Laser DUTY select low speed (Y) 0 - 255 0
0 ✕
AC LASER DUTY MIDDLE (BW) Laser DUTY select middle speed (BW) 0 - 255 0
0 ✕
AD LASER DUTY LOW (BW) Laser DUTY select low speed (BW) 0 - 255 0
0 ✕
Mode Item/Display Content
Setting
range
De-fault value
Destination
linkage
41-sheet
machine
50-sheet
machine
1
: Oct. 24 2008
1
