Sharp MX-5001N - Page 271

MX-5001N SIMULATION 6 – 124
62-6
Purpose
Operation test/check
Function (Purpose)
Used to perform the self diagnostics of the
hard disk.
Section
Operation/Procedure
1) Select the self diag area.
2) Press [EXECUTE] key.
The self diag operation is performed.
NOTE:
E7-03 error occurs. If there may be a trouble in the HDD, use this
simulation to cheek the HDD.
When the operation is completed, [EXECUTE] key returns to the
normal display.
Normal completion → "OK(RESULT:0)" is displayed.
Abnormal end → "NG(RESULT: Other than 0)" is displayed.
* If the simulation cannot be executed or terminated abnormally for
some reason, "ERROR" is displayed on the corresponding sec-
tion.
62-7
Purpose
Operation test/check
Function (Purpose)
Used to print the hard disk self diagnostics
error log.
Section
Operation/Procedure
1) Press [EXECUTE] key.
ERROR LOG SECTOR of the SMART function is executed, and
the result is printed.
When the operation is completed, [EXECUTE] key returns to the
normal display.
62-8
Purpose
Function (Purpose) Used to format the hard disk. (Excluding
the system area and the operation manual
area)
Section
Operation/Procedure
1) Press [EXECUTE] key.
2) Press [YES] key.
Used to execute the hard disk format.
When the operation is completed, [EXECUTE] key returns to the
normal display.
* When the HDD formatting (except for the system area) is not
completed normally, "HDD FORMAT (EXCEPT SYSTEM AREA)
NG" is displayed.
62-10
Purpose
Data clear
Function (Purpose)
Used to delete the job log data.
Section
Operation/Procedure
1) Press [EXECUTE] key.
2) Press [YES] key.
Used to delete the job log data.
When the operation is completed, [EXECUTE] key returns to the
normal display.
62-11
Purpose
Data clear
Function (Purpose)
Used to delete the document filing data.
Section
Operation/Procedure
1) Press [EXECUTE] key.
2) Press [YES] key.
Used to delete the document filing data.
When the operation is completed, [EXECUTE] key returns to the
normal display.
SHORT S.T Partial area diag
EXTENDED S.T All area diag
ǂǂǂ6,08/$7,21
ǂǂ12
&/26(
7(67
60$572))/,1(7(67





6+25767
˖(1$%/(
(;7(1'('67
˖',6$%/(
(;(&87(
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
60$57(5525/2*35,17287


(;(&87(
35(66>(;(&87(@7235,177+(60$57(552535,17
ǂǂǂ6,08/$7,21
ǂǂ12
&/26(
7(67
+'')250$7(;&(376<67(0$5($


$5(<28685("
<(6 12 (;(&87(
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
-2%&203/(7('$7$&/($5:,7+-2%/2*'$7$


$5(<28685("
<(6 12 (;(&87(
