COPIER
Contents
Staple sort function
The staple sort function sorts output into sets, staples each set, and delivers the sets to the tray.
The relations between the stapling positions, paper orientation, permitted paper sizes for stapling, and number of sheets
that can be stapled are shown below.
For original placement orientations, see "Original placement orientation" (page 2-34).
Original placement orientation
When using the staple sort function, the original must be placed as shown below to enable stapling in the desired
position on the paper.
Stapling positions Paper
Applicable paper sizes
8-1/2" x 14", 8-1/2" x 13-1/2", 8-1/2" x 13-2/5", 8-1/2" x 13", 8-1/2" x 11", 7-1/4" x 10-1/2", A4, B5,
16K
Number of sheets that can be stapled
Max. 30 sheets
Document feeder tray Document glass
Staple sort
abc
A
A
A
A
A
A
A
A
