2-72
COPIER
Contents
[Image Edit] KEY
When the [Image Edit] key is touched in t
he 1st special modes menu screen, the image edit menu screen opens.
Image edit menu screen
(1)
[Photo Repeat] key
☞
REPEATING PHOTOS ON
A COPY (Photo Repeat)
(page 2-73)
(2)
[Mirror Image] key
☞
REVERSING THE IMAGE (Mirror Image)
(page
2-75)
(3)
[Centering] key
☞
COPYING IN THE CE
NTER OF THE PAPER
(Centering)
(page 2-76)
(4)
[B/W Reverse] key
☞
REVERSING BLACK AND WHITE IN A COPY (B/W
Reverse)
(page 2-78)
OK
Mirror
B/W
Re
v
erse
Centering
Repeat
OK
Special
Modes
Edit
Special
Modes
OK
1
2
Card
Shot
2in1
Stamp
File
Transparency
Inserts
Erase
Job
Build
Edit
Quick
Fi
le
Margin
Shift
Pamphlet
Copy
Sharpness
(1)
(2)
(3)
(4)
155
