1-13
BEFORE USING THE MACHINE
Contents
(3)
Brightness adjustment key
Touch this key to adjust the brightn
ess of the touch
panel.
When touched, the fo
llowing screen appears ne
xt to the
key.
Touch the [+] key or the [-]
key to adjust the brightness.
When finished, touch the brightness adjus
tment key
again to close the screen.
This icon appears wh
en the data security
kit
is being used.
The icon appears when th
e machine is
communicating with an external appl
ication.
51
53
