33
INSTALLING THE PRINTER DRIVER / PC-FAX DRIVER
1
Click the [Pri
nter Driver] button.
To install the PC-F
ax driver, click the [P
C-Fax Driv
er] button on the "Disc
2" CD-ROM.
*The above screen appe
ars when using the "Disc
1" CD-ROM.
2
Click the [Cus
tom installation] but
ton.
3
Select [Share
d Printer] and click th
e [Next] button.
