51
CHANGING THE PORT
6
Configure the port settings.
(1) Select [LPR].
(2) Enter [lp].
(3) Click the [OK] button.
7
Click the [Next] button in the screen of step 5.
8
Click the [Finish] button.
9
Click the [Close] button in the screen of step 2.
When using a port created with "Standard TCP/IP Port"
When using a port created using "Standard TCP/IP Port" in Windows
2000/XP/Server 2003/Vista/Server 2008, in the screen that appears after you
click the [Configure Port] button in the screen of step 3, make sure the [SNMP
Status Enabled] checkbox is not selected ( ). If the [SNMP Status Enabled]
checkbox is selected ( ), it may not be possible to print correctly.
(2) (3)
(1)
