30
REPLACING SUPPLIES AND MAINTENANCE
4
Remove the empty staple cartridge from the staple case.
Gently grasp the right side of the staple cartridge as shown and lift to the left
and up. The lock will release easily. After the lock releases, continue lifting the
staple cartridge to the left and up to remove it.
• Even when a message appears in the operation panel, staples may
occasionally remain in the staple cartridge.
• If staples remain, the lock will not release easily. Forcing the lock to
release may deform the staple case and staple cartridge, causing
failure.
5
Insert a new staple cartridge into the staple case
as shown.
Push the staple cartridge in until it clicks into place.
mxb401_us_saf.book 30 ページ ２００９年１月７日 水曜日 午後３時３３分
To Next Page
