Sharp MX-C250F Technical Handy Guide

TEST SIMULATION
SHARP
48
The following pages contain information regarding test simulations. For a detailed description for each
test simulation, please refer to the MX-C250/300/301W series Service Manual.
Entry Code:
1
Scanner Self Test
1
Scanner operation test
2
Scanner sensor check
5
Scanner unit and control circuit check
[MX-C301W]
2
SPF Self Test
1
SPF ageing test.
2
SPF sensor check
3
SPF output check (motor, clutch, solenoid)
5
Lamp Operation & Test
1
LCD/LED operation panel test
2
Heater lamp load check
3
Scanner lamp control circuit check
4
Discharge lamp control circuit check
6
System Load Operation & Test
1
Paper Feed output / load check
2
Fan control circuit check
3
Transport unit control circuit check
90
Reset machine to factory setting (scanner
mirror unit lock position execute).
7
Device Aging Operation & Test
1
Ageing test setting
6
Interval ageing cycle timer set up
8
Warm up time display setting [MX-C301W]
9
Printing colour select mode (colour)
12
Document reading setting (aging)
8
High Voltage Operation & Test
1
Developer bias setting and output
2
MHV/Grid setting and output
6
Transfer setting and output
10
Toner Motor Operation & Test
1
Toner motor operation check
13
U1 Clear / Cancel
--
Trouble cancel (U1 trouble) [MX-C301W]
14
Clear / Cancel
--
Trouble cancel (excluding U2/PF trouble).
16
U2 Clear / Cancel
--
U2 trouble cancel
21
Maintenance Cycle Configuration
1
Maintenance cycle setting
22
Data Output & Check
1
Counter data display
2
Jam/trouble counter display
3
Jam history data display
4
Trouble code history data display
5
ROM version display
6
Data print mode
8
SPF & Scanner output counter display
9
Paper feed counter display
10
Machine system display
11
Fax counter display
12
SPF jam history display
13
Process cartridge counter display
14
Toner cartridge use status
15
Toner usage history display [MX-C301W]
18
User data delete history [MX-C301W]
19
Image Send counter display
25
Toner usage estimator data display
[MX-C301W]
40
Error code list display
42
Jam/Trouble data check [MX-C301W]
43
Jam data details display [MX-C301W]
90
System setting list print [MX-C301W]
23
Data Print Mode & Check
2
Print jam/Trouble data print mode
80
Paper feed & transport operation status
(output list) [MX-C301W]
81
Paper feed & transport operation status
(receive list) [MX-C301W]
