36
MAC OS 9.0 - 9.2.2
10
Select the PPD file.
(1) Click the PPD file for your
model.
(2) Click the [Select] button.
11
Make sure that the machine is
selected in the "Select a
PostScript Printer" list and then
click the [Setup] button.
12
Click the [Configure] button.
13
Select the machine
configuration.
(1) Select the options that are
installed on the machine.
(2) Select [Options 2] from the
menu to change the screen and
continue selecting the options
that have been installed on the
machine.
(3) Click the [OK] button.
14
Click the [OK] button in the
window of step 12 to close the
window.
• If the above dialog box does not
appear and you return to the
"Chooser" dialog box, follow these
steps to select the PPD file
manually.
(1)Make sure that the machine is
selected in the "Select a
PostScript Printer" list, and then
click the [Setup] button followed
by the [Select PPD] button.
(2)Select the PPD file for your
model and click the [Open]
button.
(3)Click the [OK] button.
• The PPD file is installed in the
[Printer Descriptions] folder in the
[Extensions] folder.
(1)
(2)
Note
To automatically configure the settings
based on the installed machine
options that are detected, click the
[Auto Setup] button.
You can check the options that are
installed on the machine by printing
out the "PRINTER SETTINGS LIST" in
the system settings. (However, note
that "Input Tray Options" must be set
to the number of trays on the
machine.) Follow these steps to print
out the "PRINTER SETTINGS LIST":
Press the [SYSTEM SETTINGS] key,
touch the [LIST PRINT] key,
"PRINTER TEST PAGE" key and then
touch the "PRINTER SETTINGS
LIST" key.
Note
Note
