Sharp MX-M363F User Manual

– 9-4 –
Update : 2010/11/30
9
SCN ｺﾝﾄﾛｰﾙ基板ﾕﾆｯﾄ (SCN control PWB unit)
NO.
PARTS CODE
Inter-
change
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
TR No.
Effective
time
Ex. Ja.
34
VRSRCZ1JD102JN AA DD C
Resistor(1/16W 1kΩ ±5%)
[R31,R118,R152,R153,R171] 抵抗
VRSRCZ1JD102JN AA DD C
Resistor(1/16W 1kΩ ±5%)
[R203,R204,R220,R224,R231] 抵抗
VRSRCZ1JD102JN AA DD C
Resistor(1/16W 1kΩ ±5%)
[R242,R317,R318,R333] 抵抗
VRSRCZ1JD102JN AA DD C
Resistor(1/16W 1kΩ ±5%)
[R363,R365,R370,R373] 抵抗
VRSRCZ1JD102JN AA DD C
Resistor(1/16W 1kΩ ±5%) (MX-M283N/M363N/
M453N/M503N/M282N/M362N/M452N/M502N)
[R330,R335,R337,R343,R354] 抵抗
VRSRCZ1JD102JN AA DD C
Resistor(1/16W 1kΩ ±5%)
(Except MX-M363N/M453N/M503N)
[R272,R273,R274,R275,R276,R277,R366,R374] 抵抗
VRSRCZ1JD102JN AA DD C
Resistor(1/16W 1kΩ ±5%) [R227,R355,R360] 抵抗
VRSRCZ1JD102JN AA DD C
Resistor(1/16W 1kΩ ±5%) (MX-M363F/M423F/
M503F/M363U/M453U/M503U)
[R355] 抵抗
35 VRSRCZ1JD105FN AA DD C
Resistor(1/16W 1kΩ ±1%) [R22,R325] 抵抗
36 VRSRCZ1JD105JN AA DD C
Resistor(1/16W 1kΩ ±5%) [R50,R250,R326] 抵抗
37 VRSRCZ1JD203JN AA DD C
Resistor(1/16W 20kΩ ±5%) [R7] 抵抗
38 VRSRCZ1JD220JN AA DD C
Resistor(1/16W 22Ω ±5%) (MX-M363N/M453N/M503N)
[R278,R293,R294,R295,R296] 抵抗
39 VRSRCZ1JD273FN AA DD C
Resistor(1/16W 27KΩ ±1%) [R140] 抵抗
40 VRSRCZ1JD202FN AA DD C
Resistor(1/16W 2KΩ ±1%) [R148] 抵抗
41 VRSRCZ1JD332FN AA DD C
Resistor(1/16W 3.3kΩ ±1%) [R142] 抵抗
42 VRSRCZ1JD392FN AA DD C
Resistor(1/16W 3.9KΩ ±1%) [R146] 抵抗
43 VRSRCZ1JD392JN AA DD C
Resistor(1/16W 3.9KΩ ±5%) [R341] 抵抗
44 VRSRCZ1JD303FN AA DD C
Resistor(1/16W 30kΩ ±1%) [R321] 抵抗
45 VRSRCZ1JD303JN AA DD C
Resistor(1/16W 30kΩ ±5%) [R10] 抵抗
46 VRSRCZ1JD331JN AA DD C
Resistor(1/16W 330Ω ±5%) [R249] 抵抗
47
VRSRCZ1JD330JN AA DD C
Resistor(1/16W 33Ω ±5%)
[R89,R95,R104,R105,R107,R110,R124] 抵抗
VRSRCZ1JD330JN AA DD C
Resistor(1/16W 33Ω ±5%)
[R134,R184,R193,R213,R246,R252,R268] 抵抗
VRSRCZ1JD330JN AA DD C
Resistor(1/16W 33Ω ±5%)
[R280,R286,R291,R292,R316,R342,R350,R351] 抵抗
VRSRCZ1JD330JN AA DD C
Resistor(1/16W 33Ω ±5%) (MX-M283N/M363N/
M453N/M503N/M282N/M362N/M452N/M502N)
[R108,R109,R111,R165,R183,R187,R382] 抵抗
VRSRCZ1JD330JN AA DD C
Resistor(1/16W 33Ω ±5%) (MX-M363F/M423F/
M503F/M363U/M453U/M503U)
[R113,R114,R119,R205] 抵抗
VRSRCZ1JD330JN AA DD C
Resistor(1/16W 33Ω ±5%)
[R102,R103,R106,R116] 抵抗
VRSRCZ1JD330JN AA DD C
Resistor(1/16W 33Ω ±5%)
[R129,R163,R164,R173] 抵抗
VRSRCZ1JD330JN AA DD C
Resistor(1/16W 33Ω ±5%)
[R194,R198,R206,R334,R353,R359] 抵抗
VRSRCZ1JD330JN -AADD C
Resistor(1/16W 33Ω ±5%)
(MX-M363N/M453N/M503N)
[R177,R282,R500,R501] 抵抗
10/04 R/C
VRSRCZ1JD330JN -AADD C
Resistor(1/16W 33Ω ±5%) (MX-M363F/M423F/
M503F/M363U/M453U/M503U)
[R175,R177,R500] 抵抗
10/04 R/C
VRSRCZ1JD330JN -AADD C
Resistor(1/16W 33Ω ±5%) (MX-M283N/M282N/
M362N/M452N/M502N)
[R175,R177,R500,R501] 抵抗
10/04 R/C
48 VRSRCZ1JD393JN AA DD C
Resistor(1/16W 39KΩ ±5%) [R8,R9] 抵抗
49
VRSRCZ1JD472JN AA DD C
Resistor(1/16W 4.7kΩ ±5%)
[R6,R16,R19,R51,R188,R340] 抵抗
VRSRCZ1JD472JN AA DD C
Resistor(1/16W 4.7kΩ ±5%) [R91,R378] 抵抗
50
VRSRCZ1JD471JN AA DD C
Resistor(1/16W 47Ω ±5%) [R255,R301,R302] 抵抗
VRSRCZ1JD471JN -AADD C
Resistor(1/16W 47Ω ±5%) [R302] 抵抗
09/12
VRSRCZ1JD471JN -AADD C
Resistor(1/16W 47Ω ±5%) [R301] 抵抗
10/12
51 VRSRCZ1JD473JN AA DD C
Resistor(1/16W 47KΩ ±5%)
[R53,R131,R132,R137,R138] 抵抗
52 VRSRCZ1JD512FN -AADD C
Resistor(5.1KF(1005)) [Missing parts code][R147] 抵抗
1st lot
53 VRSRCZ1JD562JN AA DD C
Resistor(1/16W 5.6KΩ ±5%) [R12,R28,R34,R43] 抵抗
54 VRSRCZ1JD682FN -AADD C
Resistor(6.8KF(1005)) [Missing parts code][R150] 抵抗
1st lot
55 VRSRCZ1JD624JN AA DD C
Resistor(1/16W 620KΩ ±5%) [R42] 抵抗
56
VRSRCZ1JD680JN AA DD C
Resistor(1/16W 68Ω ±5%)
[R265,R283,R284,R285] 抵抗
VRSRCZ1JD680JN AA DD C
Resistor(1/16W 68Ω ±5%) [R56,R58] 抵抗
57 VRSRCZ1JD752JN AA DD C
Resistor(1/16W 7.5KΩ ±5%) [R49] 抵抗
58
VRSRCY1JD000JN AA DD C
Resistor(1/16W 0Ω ±5%) [RB1,RB2,RB31,RB100] 抵抗
VRSRCY1JD000JN -AADD C
Resistor(1/16W 0Ω ±5%) [RB1,RB2,RB31,RB100] 抵抗
10/04 R/C
VRSRCY1JD000JN AA DD C
Resistor(1/16W 0Ω ±5%) [RB29,RB30,RB101] 抵抗
59
VHPLT1F67AF-1- -ACDJN B
LED(LT1F67AF) [Missing parts code][LED1,LED2] LED
1st lot
VHPLT1F67AF-1- -ACDJN B
LED(LT1F67AF) [LED2] LED
10/12
