Sharp MX-M363F User Manual

– 9-5 –
Update : 2010/11/30
9
SCN ｺﾝﾄﾛｰﾙ基板ﾕﾆｯﾄ (SCN control PWB unit)
NO.
PARTS CODE
Inter-
change
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
TR No.
Effective
time
Ex. Ja.
60 VHI012EHZPH-1R AH DX B
IC(Regulator)(PQ012EHS2ZPH) (MX-M283N/M363N/
M453N/M503N/M282N/M362N/M452N/M502N)
[IC26] IC
61 RH-IX0058FCPZQ AT EQ B
IC(SDRAM)(K4S641632N-LC75) [IC7,IC8] IC(SDRAM)
62
VCERUL1HM224ML -AHDX C
Capacitor(0.22UF/50V(UL)) [Missing parts code]
[C2,C3] ｺﾝﾃﾞﾝｻｰ
1st lot
VCKYRZ1CB224KN 1ABDJ C
Capacitor(0.22UF/16V) [CB316,CB321] ｺﾝﾃﾞﾝｻｰ
11/01
63
VCERUL1VM226ML -AHDX C
Capacitor(22UF/35V(UL)) [Missing parts code]
[C5,C6,C8,C9,C10,C11,C16] ｺﾝﾃﾞﾝｻｰ
1st lot
VCERUL1VM226ML -AHDX C
Capacitor(22UF/35V(UL)) [Missing parts code][C16] ｺﾝﾃﾞﾝｻｰ
1st lot
VCERUL1VM226ML -AHDX C
Capacitor(22UF/35V(UL)) [Missing parts code][C13] ｺﾝﾃﾞﾝｻｰ
1st lot
64 VHI74L16212-1L AN EG B
IC(BUSSWITCH)(74CBTLV16212PAG8) (MX-M283N/
M363N/M453N/M503N/M282N/M362N/M452N/M502N)
[IC19,IC22] IC
65 VHIICSV104Y-1L AP EQ B
IC(FPDLINK)(ICSV104YLFT) [IC13] IC
66 VHIICSV385A-1L AL EB B
IC(FPDLINK)(ICSV385AGLFT) [IC20] IC
67
VHIICSV386+-1L AL EB B
IC(FPDLINK)(ICSV386GLFT) [IC34] IC
VHIVP386PAG-1L 3ALEBN B
IC(IDTVP386PAG8) [Improve performance]
[IC34] IC
09/04 mid
69 VHIC25811SZ-1L AK DX B
IC(SS)(CY25811SXCT) [IC11,IC30] IC
70 VRSRTL2JFR20JN -ACDD C
Resistor(0.2J(3225)) [Missing parts code]
[RB27,RB28] 抵抗
1st lot
71
RH-IX7001XCPZL AN EQ B
SRAM(IS63LV1024L-12JL) [IC28] SRAM
RH-IX0080FCPZL 1AREQ B
IC(SRAM)(IS63LV1024L-12JL) [IC28] IC
10/04
RH-IX0099FCPZL 1APEQ B
IC [IC28] IC
10/12
72 VHISNCL383P-1L AG DX B
IC(BUSSWITCH)(SN74CBTLV3383PWR)
(MX-M363N/M453N/M503N)
[IC25] IC
73 VHILM324D++-17 AE DJ B
IC(OPAMP)(LM324DR) [ICB1] IC
75 QCNCM1487FCPZL AL EB C
Connector(FI-RE41S-VF) [CN10] ｺﾈｸﾀｰ
76 VSUPA502TA+-1L AD DJ B
FET(UPA502T-T1-A) [Q29] FET
77 VHI658920130CQ AN EQ B
IC(ASIC)(IOASIC(SC65892)) [IC39] IC
78 VHI800809F11CQ BE GN B
IC(ASIC)(SCAN-ASIC(SC800809)) [IC12] IC
79 RFILN0313FCPZN AA DJ C
Filter(BLM18PG121SN1(1608))
[L1,L2,L3,L4,L5,L9] ﾌｨﾙﾀｰ
80 RCILF0133FCPZN AE DS C
Coil(DLP2ADN900HL4) [L6,L7,L8] ｺｲﾙ
81 RCRMC0012FCPZL AF DS B
Crystal(CSTCE_G(19.6608MHz)) [X2] ｸﾘｽﾀﾙ
82 VCKYRZ1HF103ZN AA DD C
Capacitor(0.01µF(1005:F:50V)) [CB317] ｺﾝﾃﾞﾝｻｰ
83
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF) [CB1,CB2,CB3,CB4,
CB5,CB8,CB9,CB10,CB11,CB13,CB14] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF) [CB15,CB17,CB18,
CB23,CB24,CB27,CB29,CB33,CB34] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF) [CB35,CB38,CB39,
CB40,CB41,CB43,CB44,CB45,CB48,CB50] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF) [CB54,CB56,CB61] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF) [CB62,CB64,CB68,
CB69,CB75,CB84,CB86,CB87,CB90,CB93] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF)
[CB95,CB98,CB99,CB102,CB103,CB104,CB105] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF) [CB111,CB114,CB115] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF)
[CB143,CB156,CB159,CB161,CB162,CB174] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF) [CB175,CB176,CB177,
CB178,CB179,CB181,CB184,CB186] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF) [CB188,CB190,CB191,
CB192,CB196,CB198,CB200,CB201] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF) [CB203,CB204,CB205,
CB207,CB209,CB211,CB213,CB215] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF)
[CB216,CB217,CB219,CB221] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF)
[CB222,CB223,CB224,CB225] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF)
[CB227,CB228,CB229,CB231] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF)
[CB233,CB235,CB236,CB237] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF)
[CB238,CB242,CB244,CB246] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF)
[CB249,CB252,CB253,CB255] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF)
[CB257,CB259,CB260,CB261] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF)
[CB263,CB264,CB265,CB266] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF)
[CB268,CB270,CB271,CB273] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF)
[CB274,CB275,CB276,CB288] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF)
[CB290,CB291,CB292,CB293] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF)
[CB294,CB295,CB296,CB298] ｺﾝﾃﾞﾝｻｰ
