Sharp MX-M363F User Manual

– 10-1 –
Update : 2010/11/30
F
DSPF ｺﾝﾄﾛｰﾙ基板 (DSPF control PWB unit)Except MX-M282N/M362N/M452N/M502N
NO.
PARTS CODE
Inter-
change
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
TR No.
Effective
time
Ex. Ja.
1
QCNCW1424FCPZL AE DS C
Connector(BM06B-GHS-TBT(LF)(SN)) [CN1] ｺﾈｸﾀｰ
QCNCW1424FCPZL -AEDS C
Connector(BM06B-GHS-TBT(LF)(SN)) [CN1] ｺﾈｸﾀｰ
09/12
2
VHDDAN202U/-14 AB DJ B
Diode(DAN202U) [D2,D4,D5,D7,
D9,D13,D14,D15,D19,D20,D21,D22,D23] ﾀﾞｲｵｰﾄﾞ
VHDDAN202U/-14 AB DJ B
Diode(DAN202U)
[D24,D25,D26,D27,D28,D29,D30] ﾀﾞｲｵｰﾄﾞ
3
VHDDAP202U/-14 AB DJ B
Diode(DAP202U) [D3,D6,D8,D10,
D11,D16,D17,D32,D33,D34,D35,D36,D37] ﾀﾞｲｵｰﾄﾞ
VHDDAP202U/-14 AB DJ B
Diode(DAP202U)
[D38,D39,D40,D41,D42,D43] ﾀﾞｲｵｰﾄﾞ
4 VSDTC114YUB-1L AB DJ B
Transistor(DTC114YUBTL)
[Q1,Q2,Q4,Q5,Q6,Q7,Q8,Q10,Q11,Q12,Q13] ﾄﾗﾝｼﾞｽﾀｰ
5 VHIBA00DDWH-1R AG DX B
IC(BA00DD0WHFP-TR) [IC19,IC28,IC29] IC
6
VRSRTP2BD000JN AA DD C
Resistor(1/8W 0Ω ±5%) [R243,R244,R249,
R250,R251,R255,R257,R261,R262,R263] 抵抗
VRSRTP2BD000JN AA DD C
Resistor(1/8W 0Ω ±5%) [R264] 抵抗
7 RMPTR4101ACPZN AA DD B
Block resistor(100Ω×4 ±5%)
[BR31,BR34,BR35,BR62] ﾌﾞﾛｯｸ抵抗
8 RMPTR4100ACPZN AA DD B
Block resistor(10JX4(1005x4)) [BR42,BR43,BR46] ﾌﾞﾛｯｸ抵抗
9
RMPTR4103ACPZN AA DD B
Block resistor(10KΩ×4 ±5%) [BR1,BR2,BR6,BR7,
BR8,BR9,BR16,BR17,BR18,BR19,BR20] ﾌﾞﾛｯｸ抵抗
RMPTR4103ACPZN AA DD B
Block resistor(10KΩ×4 ±5%)
[BR21,BR30,BR32,BR33,BR47,BR63] ﾌﾞﾛｯｸ抵抗
10
RMPTR4330ACPZN AA DD B
Block resistor(33Ω×4 ±5%) [BR5,BR10,BR11,BR12,
BR13,BR14,BR15,BR48,BR49,BR50] ﾌﾞﾛｯｸ抵抗
RMPTR4330ACPZN AA DD B
Block resistor(33Ω×4 ±5%) [BR51,BR52,BR53,BR54,
BR55,BR56,BR57,BR58,BR59,BR60] ﾌﾞﾛｯｸ抵抗
RMPTR4330ACPZN AA DD B
Block resistor(33Ω×4 ±5%) [BR61] ﾌﾞﾛｯｸ抵抗
11 RMPTR4470ACPZN AA DD B
Block resistor(47Ω×4 1/16W ±5%)
[BR64,BR65,BR67,BR68] ﾌﾞﾛｯｸ抵抗
12
RMPTR4680ACPZN AA DD B
Block resistor(68Ω×4 ±5%) [BR3,BR4,BR22,BR23,
BR24,BR25,BR26,BR27,BR28,BR29] ﾌﾞﾛｯｸ抵抗
RMPTR4680ACPZN AA DD B
Block resistor(68Ω×4 ±5%)
[BR36,BR37,BR38,BR39,BR40,BR41,BR44,BR45] ﾌﾞﾛｯｸ抵抗
13
VRSRCZ1JD000JN AA DD C
Resistor(1/16W 0Ω ±5%)
[R12,R64,R65,R67,R69,R87,R90,R92,R94,R160,R163] 抵抗
VRSRCZ1JD000JN AA DD C
Resistor(1/16W 0Ω ±5%)
[R170,R182,R195,R196,R212,R219,R220,R265] 抵抗
14 VRSRCZ1JD132FN -AADD C
Resistor(1.3KF(1005)) [Missing parts code]
[R154] 抵抗
1st lot
15
VRSRCZ1JD101JN AA DD C
Resistor(1/16W 100Ω ±5%) [R17,R20,R44,R45,
R46,R52,R54,R56,R98,R99,R101,R103] 抵抗
VRSRCZ1JD101JN AA DD C
Resistor(1/16W 100Ω ±5%) [R105,R107,R108,
R110,R111,R113,R114,R115,R124,R125] 抵抗
VRSRCZ1JD101JN AA DD C
Resistor(1/16W 100Ω ±5%) [R127,R128,R129,
R130,R131,R132,R133,R134,R139,R142] 抵抗
VRSRCZ1JD101JN AA DD C
Resistor(1/16W 100Ω ±5%) [R145,R188,R203,
R207,R223,R225,R234,R235,R236,R237] 抵抗
VRSRCZ1JD101JN AA DD C
Resistor(1/16W 100Ω ±5%) [R238,R239] 抵抗
16 VRSRCZ1JD104JN AA DD C
Resistor(1/16W 100kΩ ±5%)
[R242,R256,R258,R267] 抵抗
17
VRSRCZ1JD100JN AA DD C
Resistor(1/16W 10Ω ±5%) [R164,R165,R166,
R167,R168,R169,R183,R184,R187,R192] 抵抗
VRSRCZ1JD100JN AA DD C
Resistor(1/16W 10Ω ±5%) [R200,R201] 抵抗
18
VRSRCZ1JD103JN AA DD C
Resistor(1/16W 10KΩ ±5%) [R4,R5,R18,R21,
R22,R25,R27,R28,R32,R34,R36,R39,R41] 抵抗
VRSRCZ1JD103JN AA DD C
Resistor(1/16W 10KΩ ±5%) [R42,R49,R59,R61,
R71,R74,R78,R80,R84,R85,R121,R135] 抵抗
VRSRCZ1JD103JN AA DD C
Resistor(1/16W 10KΩ ±5%) [R146,R152,R155,
R161,R162,R209,R218,R224,R228,R231] 抵抗
VRSRCZ1JD103JN AA DD C
Resistor(1/16W 10KΩ ±5%)
[R232,R245,R246,R260] 抵抗
19 VRSRCZ1JD153FN AA DD C
Resistor(1/16W 15kΩ ±1%) [R254] 抵抗
20 VRSRCZ1JD102FN AA DD C
Resistor(1/16W 1KΩ ±1%(1005)) [R181] 抵抗
21
VRSRCZ1JD102JN AA DD C
Resistor(1/16W 1kΩ ±5%) [R10,R43,R47,R53,
R55,R57,R100,R102,R104,R106,R109] 抵抗
VRSRCZ1JD102JN AA DD C
Resistor(1/16W 1kΩ ±5%)
[R112,R126,R140,R141,R144] 抵抗
22 VRSRCZ1JD105JN AA DD C
Resistor(1/16W 1kΩ ±5%) [R8,R189] 抵抗
23 VRSRCZ1JD273FN AA DD C
Resistor(1/16W 27KΩ ±1%) [R241] 抵抗
24 VRSRCZ1JD332FN AA DD C
Resistor(1/16W 3.3kΩ ±1%) [R253] 抵抗
25 VRSRCZ1JD392FN AA DD C
Resistor(1/16W 3.9KΩ ±1%) [R240] 抵抗
26 VRSRCZ1JD392JN AA DD C
Resistor(1/16W 3.9KΩ ±5%) [R97] 抵抗
27 VRSRCZ1JD303JN AA DD C
Resistor(1/16W 30kΩ ±5%)
[R116,R136,R137,R138] 抵抗
28 VRSRCZ1JD331JN AA DD C
Resistor(1/16W 330Ω ±5%) [R3] 抵抗
29
VRSRCZ1JD330JN AA DD C
Resistor(1/16W 33Ω ±5%) [R6,R7,R9,R11,R19,
R29,R33,R37,R50,R63,R72,R73,R76] 抵抗
VRSRCZ1JD330JN AA DD C
Resistor(1/16W 33Ω ±5%) [R81,R122,R156,R157,
R158,R159,R171,R172,R175,R176] 抵抗
10
10
