– 10-2 –
Update : 2010/11/30
F
DSPF ｺﾝﾄﾛｰﾙ基板 (DSPF control PWB unit)Except MX-M282N/M362N/M452N/M502N
NO.
PARTS CODE
Inter-
change
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
TR No.
Effective
time
Ex. Ja.
29
VRSRCZ1JD330JN AA DD C
Resistor(1/16W 33Ω ±5%) [R178,R179,R180,R191,
R202,R204,R205,R213,R214,R216] 抵抗
VRSRCZ1JD330JN AA DD C
Resistor(1/16W 33Ω ±5%) [R217,R222,R227] 抵抗
30 VRSRCZ1JD472JN AA DD C
Resistor(1/16W 4.7kΩ ±5%) [R96,R143] 抵抗
31
VRSRCZ1JD471JN AA DD C
Resistor(1/16W 47Ω ±5%) [R16,R23,R89] 抵抗
VRSRCZ1JD471JN -AADD C
Resistor(1/16W 47Ω ±5%) [R23] 抵抗
09/12
VRSRCZ1JD471JN -AADD C
Resistor(1/16W 47Ω ±5%) [R16] 抵抗
10/12
32 VRSRCZ1JD473JN AA DD C
Resistor(1/16W 47KΩ ±5%) [R215,R233,R248] 抵抗
33 VRSRCZ1JD682FN -AADD C
Resistor(6.8KF(1005)) [Missing parts code]
[R153] 抵抗
1st lot
34
VHPLT1F67AF-1- -ACDJN B
LED(LT1F67AF) [Missing parts code]
[LED1,LED3] LED
1st lot
VHPLT1F67AF-1- -ACDJN B
LED(LT1F67AF) [LED1] LED
10/12
35 RH-IX0039FCPZQ BA FX B
SDRAM(256MbitSDRAM(x8))
[IC9,IC10,IC11,IC12,IC15,IC16,IC17,IC18] SDRAM
36 VCERUL1VM226ML -AHDX C
Capacitor(22UF/35V(UL)) [Missing parts code]
[C146,C156,C161] ｺﾝﾃﾞﾝｻｰ
1st lot
37 VHIICSV104Y-1L AP EQ B
IC(ICSV104YLFT) [IC26] IC
38 VHIICSV385A-1L AL EB B
IC(ICSV385AGLFT) [IC25] IC
39 VHIC25811SZ-1L AK DX B
IC(CY25811SXCT) [IC2,IC22] IC
40 VHI23S09SZ+-1L AN EQ B
IC(CY23S09SXC-1T) [IC20] IC
41
RH-IX7001XCPZL AN EQ B
IC(IS63LV1024L-12JL) [IC6] IC
RH-IX0080FCPZL 1AREQ B
IC(IS63LV1024L-12JL) [IC6] IC
10/04
RH-IX0099FCPZL 1APEQ B
IC [IC6] IC
10/12
42 VHILM324D++-17 AE DJ B
IC(LM324DR) [ICB1] IC
44 VHI800809F11CQ BE GN B
IC(SCAN-ASIC(SC800809)) [IC23] IC
45 RFILN0313FCPZN AA DJ C
Filter(BLM18PG121SN1(1608))
[L1,L2,L3,L5,L8,L9] ﾌｨﾙﾀｰ
46 RCILF0133FCPZN AE DS C
Coil(DLP2ADN900HL4) [L4,L6,L7] ｺｲﾙ
47 RCRMC0012FCPZL AF DS B
Crystal(CSTCE_G(19.6608MHz)) [X1] ｸﾘｽﾀﾙ
48
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF) [C1,C3,C5,C6,C8,C9,
C10,C11,C12,C13,C14,C15,C17,C18] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF) [C19,C20,C21,C23,
C24,C25,C29,C30,C31,C32,C33,C34] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF) [C40,C41,C42,C43,
C44,C45,C46,C47,C48,C49,C50,C51] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF) [C52,C53,C54,C55,
C56,C57,C58,C59,C60,C61,C62,C63] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF) [C64,C65,C66,C67,
C68,C69,C70,C71,C76,C77,C78,C79] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF) [C80,C81,C82,C83,
C84,C85,C86,C87,C88,C89,C92,C93] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF) [C94,C95,C96,C98,
C99,C100,C101,C103,C104,C105,C106] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF) [C107,C108,C110,
C112,C113,C114,C115,C118,C119,C122] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF) [C123,C125,C126,
C127,C128,C129,C130,C131,C133,C134] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF) [C135,C137,C139,
C140,C142,C150,C151,C153,C154,C155] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF) [C160] ｺﾝﾃﾞﾝｻｰ
49
VCKYRY1CF104ZN AA DD C
Capacitor(0.1µF(1608:F:16V)) [CB9,CB14,CB17,
CB18,CB20,CB21,CB24,CB25,CB26,CB28] ｺﾝﾃﾞﾝｻｰ
VCKYRY1CF104ZN AA DD C
Capacitor(0.1µF(1608:F:16V)) [CB30,CB31,CB34,
CB36,CB37,CB38,CB39,CB40,CB43,CB44] ｺﾝﾃﾞﾝｻｰ
VCKYRY1CF104ZN AA DD C
Capacitor(0.1µF(1608:F:16V)) [CB68,CB69] ｺﾝﾃﾞﾝｻｰ
50 VCKYRZ1EB103KN AA DD C
Capacitor(25V 0.01µF) [C109,C124] ｺﾝﾃﾞﾝｻｰ
51
VCKYRZ1HB102KN AA DD C
Capacitor(50V 1000pF) [CB1,CB2,CB3,CB4,
CB5,CB6,CB7,CB8,CB11,CB12,CB41] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1HB102KN AA DD C
Capacitor(50V 1000pF) [CB42,CB45,CB46,
CB47,CB48,CB49,CB50,CB51,CB52,CB53] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1HB102KN AA DD C
Capacitor(50V 1000pF) [CB54,CB55,CB56,
CB57,CB58,CB59,CB60,CB61,CB62,CB63] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1HB102KN AA DD C
Capacitor(50V 1000pF) [CB64,CB65,CB66,
CB67,CB70,CB71,CB72,CB73,CB74,CB75] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1HB102KN AA DD C
Capacitor(50V 1000pF)
[CB77,CB78,CB79,CB80] ｺﾝﾃﾞﾝｻｰ
52 VCKYRY1HB102KN AA DD C
Capacitor(1000pF(1608:B:50V)) [CB13,CB15,CB16,
CB19,CB22,CB23,CB27,CB32,CB33,CB35] ｺﾝﾃﾞﾝｻｰ
53 VCKYRV1AF106ZN AB DD C
Capacitor(10V 10µF)
[C2,C27,C28,C35,C91,C97,C102,C136,C138] ｺﾝﾃﾞﾝｻｰ
54 VCKYRN1CB106KN AC DD C
Capacitor(10µF(3216:B:16V))
[C148,C149,C158,C159] ｺﾝﾃﾞﾝｻｰ
55 VCKYRZ1EB223KN AA DD C
Capacitor(22000pF(1005:B:25V)) [C90] ｺﾝﾃﾞﾝｻｰ
56 VCCCRZ1HH220JN AA DD C
Capacitor(50V 22pF) [C116] ｺﾝﾃﾞﾝｻｰ
57 VSSSM3J09FF-1L AD DJ B
Transistor(SSM3J09FU(TE85LF)) [Q9] ﾄﾗﾝｼﾞｽﾀｰ
58 VHI74LCX14FT1- AD DJ B
IC(TC74LCX14FT(EL)) [IC3,IC13,IC14] IC
59 VHI74LCX244FT- -AEDSN B
IC(TC74LCX244FT(EL)) [Missing parts code]
[IC1,IC27] IC
1st lot
60 VHIVHCT244F-1L AE DJ B
IC(TC74VHCT244AFT(EL)) [ICB2,ICB3] IC
61 VHITC7SA04U-1L AD DJ B
IC(TC7SA04FU) [IC24] IC
To Next Page
