– 2-3 –
Update : 2010/11/30
2
MFP 基板ﾕﾆｯﾄ (MFP PWB unit)
NO.
PARTS CODE
Inter-
change
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
TR No.
Effective
time
Ex. Ja.
18
VCKYRZ1AB104KN AA DD C
Capacitor(10V 0.1µF)
[C1088,C1093,C1094,C1095,C1096,C1099,C1103] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1AB104KN AA DD C
Capacitor(10V 0.1µF) [C1105,C1106,C1109,
1110,C1111,C1113,C1114,C1115] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1AB104KN AA DD C
Capacitor(10V 0.1µF)
[C1117,C1119,C1123] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1AB104KN AA DD C
Capacitor(10V 0.1µF) (Except South Africa)
[C224,C238,C560] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1AB104KN -AADD C
Capacitor(10V 0.1µF)
(Except South Africa,Brazil,Taiwan,Japan)
[C224,C238,C560] ｺﾝﾃﾞﾝｻｰ
10/03
VCKYRZ1AB104KN AA DD C
Capacitor(10V 0.1µF) (MX-M283N/M363N/
M453N/M503N/M282N/M362N/M452N/M502N)
[C140] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1AB104KN AA DD C
Capacitor(10V 0.1µF) (MX-M283N/M363N/
M453N/M503N/M282N/M362N/M452N/M502N)
[C200,C201] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1AB104KN AA DD C
Capacitor(10V 0.1µF) (MX-M283N/M363N/
M453N/M503N/M282N/M362N/M452N/M502N)
[C231] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1AB104KN AA DD C
Capacitor(10V 0.1µF)
(Except MX-M282N/M362N/M452N/M502N)
[C531,C532] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1AB104KN AA DD C
Capacitor(10V 0.1µF) (MX-M283N/M363N/
M453N/M503N/M282N/M362N/M452N/M502N)
[C764,C765] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1AB104KN AA DD C
Capacitor(10V 0.1µF) (MX-M283N/M363N/
M453N/M503N/M282N/M362N/M452N/M502N)
[C766,C768,C770] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1AB104KN AA DD C
Capacitor(10V 0.1µF) (MX-M283N/M363N/
M453N/M503N/M282N/M362N/M452N/M502N)
[C779,C780,C781] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1AB104KN AA DD C
Capacitor(10V 0.1µF) (MX-M283N/M363N/
M453N/M503N/M282N/M362N/M452N/M502N)
[C1092] ｺﾝﾃﾞﾝｻｰ
19
VCKYRZ0JB105KN AA DD C
Capacitor(6.3V 1µF) [C77] ｺﾝﾃﾞﾝｻｰ
VCKYRZ0JB105KN -AADD C
Capacitor(6.3V 1µF) (South Africa,Brazil)[C17] ｺﾝﾃﾞﾝｻｰ
09/12
VCKYRZ0JB105KN -AADD C
Capacitor(6.3V 1µF)
(Except South Africa,Brazil,Taiwan,Japan)[C17] ｺﾝﾃﾞﾝｻｰ
10/03
20
VCKYRZ1HB102KN AA DD C
Capacitor(50V 1000pF) [C16,C22,C32,C34,
C37,C46,C57,C58,C91,C92,C185,C195] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1HB102KN AA DD C
Capacitor(50V 1000pF) [C236,C239] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1HB102KN AA DD C
Capacitor(50V 1000pF) [C556,C571,C572,
C771,C788,C881,C955,C968,C980] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1HB102KN AA DD C
Capacitor(50V 1000pF)
[C1054,C1057,C1058,C1062] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1HB102KN AA DD C
Capacitor(50V 1000pF) (MX-M283N/M363N/
M453N/M503N/M282N/M362N/M452N/M502N)
[C769] ｺﾝﾃﾞﾝｻｰ
21
VCCCRZ1HH101JN AA DD C
Capacitor(50V 100pF) [C33] ｺﾝﾃﾞﾝｻｰ
VCCCRZ1HH101JN AA DD C
Capacitor(50V 100pF) [C1091] ｺﾝﾃﾞﾝｻｰ
22
VCKYRV1AF106ZN AB DD C
Capacitor(10V 10µF) [C11,C14,C19,C21,
C28,C36,C38,C39,C41,C47,C52,C53] ｺﾝﾃﾞﾝｻｰ
VCKYRV1AF106ZN AB DD C
Capacitor(10V 10µF) [C61,C75,C80,C83,
C84,C85,C86,C89,C90,C95,C96,C98] ｺﾝﾃﾞﾝｻｰ
VCKYRV1AF106ZN AB DD C
Capacitor(10V 10µF) [C100,C106,C110,
C117,C120,C121,C129,C145,C148] ｺﾝﾃﾞﾝｻｰ
VCKYRV1AF106ZN AB DD C
Capacitor(10V 10µF) [C164,C167,C168,
C174,C184,C188,C190,C193,C206,C215] ｺﾝﾃﾞﾝｻｰ
VCKYRV1AF106ZN AB DD C
Capacitor(10V 10µF) [C229,C243] ｺﾝﾃﾞﾝｻｰ
VCKYRV1AF106ZN AB DD C
Capacitor(10V 10µF) [C501,C502,C503,C506,
C507,C509,C511,C512,C527,C543,C544,C545] ｺﾝﾃﾞﾝｻｰ
VCKYRV1AF106ZN AB DD C
Capacitor(10V 10µF) [C546,C547,C548,C549,
C553,C554,C563,C565,C568,C590,C706,C728] ｺﾝﾃﾞﾝｻｰ
VCKYRV1AF106ZN AB DD C
Capacitor(10V 10µF) [C732,C760,C785,C798,
C840,C857,C964,C1064,C1076,C1078,C1082] ｺﾝﾃﾞﾝｻｰ
VCKYRV1AF106ZN AB DD C
Capacitor(10V 10µF)
[C1083,C1089,C1090,C1097,C1101,C1116,C1124] ｺﾝﾃﾞﾝｻｰ
VCKYRV1AF106ZN AB DD C
Capacitor(10V 10µF) (MX-M283N/M363N/
M453N/M503N/M282N/M362N/M452N/M502N)
[C157] ｺﾝﾃﾞﾝｻｰ
23
VCKYRY1AB105KN AA DD C
Capacitor(10V 1µF) [C30,C35,C49,C56,
C63,C122,C154,C156,C227,C228,C232] ｺﾝﾃﾞﾝｻｰ
VCKYRY1AB105KN AA DD C
Capacitor(10V 1µF) [C237] ｺﾝﾃﾞﾝｻｰ
VCKYRY1AB105KN AA DD C
Capacitor(10V 1µF) [C500,C505,C513,
C519,C539,C540,C690,C737,C739,C749] ｺﾝﾃﾞﾝｻｰ
VCKYRY1AB105KN AA DD C
Capacitor(10V 1µF)
[C791,C792,C1098,C1100,C1118,C1125] ｺﾝﾃﾞﾝｻｰ
VCKYRY1AB105KN AA DD C
Capacitor(10V 1µF) (MX-M283N/M363N/
M453N/M503N/M282N/M362N/M452N/M502N)
[C763] ｺﾝﾃﾞﾝｻｰ
