MFP 基板ﾕﾆｯﾄ (MFP PWB unit)
NO.
PARTS CODE
Inter-
change
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
TR No.
Effective
time
Ex. Ja.
24
VCKYRV1AB225KN AC DD C
Capacitor(10V 2.2µF) [C40,C76,C79,C99,
C105,C109,C125,C166,C198,C207] ｺﾝﾃﾞﾝｻｰ
VCKYRV1AB225KN AC DD C
Capacitor(10V 2.2µF) [C729,C733] ｺﾝﾃﾞﾝｻｰ
25 VCKYRZ1HB222KN AA DD C
Capacitor(50V 2200pF) [C564,C720] ｺﾝﾃﾞﾝｻｰ
26
VCCCRZ1HH221JN AA DD C
Capacitor(50V 220pF)
[C45,C73,C113,C114,C115,C118,C119,C137] ｺﾝﾃﾞﾝｻｰ
VCCCRZ1HH221JN AA DD C
Capacitor(50V 220pF)
[C558,C573,C735,C740,C1080] ｺﾝﾃﾞﾝｻｰ
27 VCCCRZ1HH220JN AA DD C
Capacitor(50V 22pF) [C508,C530] ｺﾝﾃﾞﾝｻｰ
28
VCKYTQ1AF226ZN -ADDD C
Capacitor(10V 22µF(3216:F)) [Missing parts code]
[C48,C62,C101,C102,C146,
C155,C196,C197,C209,C225] ｺﾝﾃﾞﾝｻｰ
1st lot
VCKYTQ1AF226ZN -ADDD C
Capacitor(10V 22µF(3216:F)) [Missing parts code]
[C727,C786,C799,C805,C814,C1126] ｺﾝﾃﾞﾝｻｰ
1st lot
29
VCKYRZ1HB471KN AA DD C
Capacitor(50V 470pF)
[C44,C144,C152,C211,C212,C213,C214] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1HB471KN AA DD C
Capacitor(50V 470pF)
[C879,C935,C936,C937,C982] ｺﾝﾃﾞﾝｻｰ
30 VCKYRZ1HB681KN AA DD C
Capacitor(50V 680pF) [C790] ｺﾝﾃﾞﾝｻｰ
31
VCCCRZ1HH8R0DN AA DD C
Capacitor(50V 8pF)
(Except MX-M282N/M362N/M452N/M502N)
[C78] ｺﾝﾃﾞﾝｻｰ
VCCCRZ1HH8R0DN AA DD C
Capacitor(50V 8pF) [C562] ｺﾝﾃﾞﾝｻｰ
VCCCRZ1HH100DN AA DD C
Capacitor(50V 10pF)
(MX-M282N/M362N/M452N/M502N)
[C78] ｺﾝﾃﾞﾝｻｰ
32 RFILN0330FCPZN -ACDJ C
Filter(NFM21PC225B0J3(2.2uF/4A))
[Missing parts code][L30,L34] ﾌｨﾙﾀｰ
1st lot
33 RFILN0331FCPZN -ADDJ C
Filter(NFM21PC475B1A3(4.7uF/6A))
[Missing parts code][L19] ﾌｨﾙﾀｰ
1st lot
34 VHD1SS355//-14 AB DJ B
Diode(1SS355) [D3,D4,D7,D8,D9] ﾀﾞｲｵｰﾄﾞ
35 VHDDAP202U/-14 AB DJ B
Diode(DAP202U) [D20,D23,D24,D25,D26] ﾀﾞｲｵｰﾄﾞ
36 VHDRB50LA30-1L AE DJ B
Diode(RB050LA-30TR) [D500,D501] ﾀﾞｲｵｰﾄﾞ
37 VHDRB461F//-14 AC DJ B
Diode(RB461FT106) [D13,D15] ﾀﾞｲｵｰﾄﾞ
38 VSTPC8021HQ-1L AG DS B
Transistor(TPC8021-H) [IC500,IC501,IC502,IC503] ﾄﾗﾝｼﾞｽﾀｰ
39
RFILN0313FCPZN AA DJ C
Filter(BLM18PG121SN1(1608))
[L1,L2,L3,L4,L5,L7,L8,L9,L10,L12,L14,L15,L16,L17] ﾌｨﾙﾀｰ
RFILN0313FCPZN -AADJ C
Filter(BLM18PG121SN1(1608)) (South Africa,Brazil)
[L4] ﾌｨﾙﾀｰ
09/12
RFILN0313FCPZN -AADJ C
Filter(BLM18PG121SN1(1608))
(Except South Africa,Brazil,Taiwan,Japan)[L4] ﾌｨﾙﾀｰ
10/03
RFILN0313FCPZN AA DJ C
Filter(BLM18PG121SN1(1608))
[L18,L20,L21,L22,L25,L26,L27,L28,L29,L31,L32,L33] ﾌｨﾙﾀｰ
RFILN0313FCPZN AA DJ C
Filter(BLM18PG121SN1(1608)) [L35,L36,L37] ﾌｨﾙﾀｰ
RFILN0313FCPZN AA DJ C
Filter(BLM18PG121SN1(1608)) [L500,L501] ﾌｨﾙﾀｰ
40
VHPLT1F67AF-1- -ACDJN B
LED(LT1F67AF) [Missing parts code]
[D2,D10,D11,D12] LED
1st lot
VHPLT1F67AF-1- -ACDJN B
LED(LT1F67AF) [Missing parts code]
[D16,D17,D18] LED
1st lot
VHPLT1F67AF-1- -ACDJN B
LED(LT1F67AF) [D16,D17,D18] LED
10/12 R/C
VHPLT1F67AF-1- -ACDJN B
LED(LT1F67AF) (Except South Africa,Brazil,Taiwan)
[D14,D19] LED
1st lot
VHPLT1F67AF-1- -ACDJN B
LED(LT1F67AF)
(Except South Africa,Brazil,Taiwan,Japan)[D14,D19] LED
10/03 1st
lot
41
VRSRCZ1JD000JN AA DD C
Resistor(1/16W 0Ω ±5%) [L502,L503,R533,R554,
R584,R644,R663,R672,R768,R776] 抵抗
VRSRCZ1JD000JN AA DD C
Resistor(1/16W 0Ω ±5%)
[R777,R816,R838,R839,R848,R850,R851] 抵抗
VRSRCZ1JD000JN AA DD C
Resistor(1/16W 0Ω ±5%)
[RJ1,RJ2,R43,R60,R62,R68,R75,R81,R120,R121] 抵抗
VRSRCZ1JD000JN AA DD C
Resistor(1/16W 0Ω ±5%)
[R125,R139,R163,R166,R281R283,R285] 抵抗
VRSRCZ1JD000JN AA DD C
Resistor(1/16W 0Ω ±5%) (Except South Africa)
[R59] 抵抗
VRSRCZ1JD000JN -AADD C
Resistor(1/16W 0W ±5%)
(Except South Africa,Brazil,Taiwan,Japan)[R59] 抵抗
10/03
VRSRCZ1JD000JN AA DD C
Resistor(1/16W 0Ω ±5%) (South Africa)
[R97,R290,R552,R852] 抵抗
VRSRCZ1JD000JN -AADD C
Resistor(1/16W 0W ±5%) (MX-M283N/M363N/M453N/
M503N Except South Africa,Brazil,Taiwan,Japan)
(R97,R290,R552,R852] 抵抗
10/03
VRSRCZ1JD000JN -AADD C
Resistor(1/16W 0W ±5%) (MX-M363U/M453U/M503U
Except South Africa,Brazil,Taiwan,Japan)
[R97,R552,R300,R301] 抵抗
10/03
VRSRCZ1JD000JN AA DD C
Resistor(1/16W 0Ω ±5%) (MX-M283N/M363N/
M453N/M503N/M282N/M362N/M452N/M502N)
[R787,R801,L38,R282] 抵抗
42
VRSRCZ1JD101FN AA DD C
Resistor(1/16W 100Ω ±1%) [R124] 抵抗
VRSRCZ1JD101FN AA DD C
Resistor(1/16W 100Ω ±1%) [R585] 抵抗
