Sharp Notevision PG-C45X - Using as a Wired Remote Control; Connecting the Remote Control to the Projector

Connecting the Projector to Other Devices
Using as a Wired Remote Control
Connecting the Remote
Control to the Projector
When the remote control cannot be used due
to the range or positioning of the projector
(rear projection, etc.), connect a ø3.5 mm
minijack cable (commercially available or
available as Sharp service part QCNW-
4870CEZZ) from the WIRED R/C JACK on the
top of the remote control to the WIRED RE-
MOTE control input terminal.
ø3.5 mm minijack cable
(commercially available or available as
Sharp service part QCNW-4870CEZZ)
To WIRED R/C JACK
WIRED REMOTE control input terminal
-26
