Sharp PG-B10S User Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
123
PG-B10S
DUNTKC053FE01
MAIN UNIT (Continued)
IC5009 VHiLV123AT+-1Y J SN74LV123APWR AF
IC5010 RH-iXA202WJN2Y J PIC12C509A-04 AP
IC5011 VHiSN1G00DC-1Y J SN74AHC1G00HDC AD
IC5012 VHiLM319M++-1Y J LM319MX AE
IC5016 VHiSNAHC157-1Y J SN74AHC2G157HD AE
IC5017 VHiSN1G86DC-1Y J SN74AHC1G86HDC AD
IC5018 VHiTVHC74T/-1Y J TC74VHC74FT AF
IC6003 VHiLV125AT+-1Y J SN74LV125APWR AE
IC6004 VHiMST9883+-1Q J MST9883-110 AY
IC6006 VHiMM3033D+-1Y J MM3033DURE AD
IC6007 VHiMM3032F+-1Y J MM3032FURE AD
IC6008 VHiPQ1L333M-1Y J PQ1L333M2SP AD
IC8001 VHiPST600iM-1Y J IC-PST600IMT AE
IC8002 VHiSNAHC14H-1Y J SN74AHC2G14HDC AE
IC8003 VHiPW164B10-1Q J PW164B-10TK BU
IC8007 VHiSN2G66CT-1Y J SN74AHC2G66HDC AE
IC8008 VSHN1K03FU+-1Y J HN1K03FU AD
IC8009 VHiSN1G66DC-1Y J SN74AHC1G66HDC AD
IC8010 VHiP2040CTR-1Y J P2040C-08TR AM
IC8011 VHiP2042ATR-1Y J P2042A-08TR AM
IC8202 RH-iXA764WJZZQ J M29W800DT70N6 AQ
IC8203 VHiBR24L64F-1Y J BR24L64F-WE2 AK
TRANSISTORS
Q1101 VS2SC3928AR-1Y J 2SC3928AR AB
Q1102 VS2SA1530AR-1Y J 2SA1530AR AB
Q1103 VS2SC3928AR-1Y J 2SC3928AR AB
Q1104 VS2SA1530AR-1Y J 2SA1530AR AB
Q1105 VSHN1C01FU/-1Y J HN1C01FU AC
Q1106 VS2SC3928AR-1Y J 2SC3928AR AB
Q1201 VS2SC3928AR-1Y J 2SC3928AR AB
Q1202 VS2SA1530AR-1Y J 2SA1530AR AB
Q1203 VS2SC3928AR-1Y J 2SC3928AR AB
Q1204 VS2SA1530AR-1Y J 2SA1530AR AB
Q1301 VS2SC3928AR-1Y J 2SC3928AR AB
Q1302 VS2SA1530AR-1Y J 2SA1530AR AB
Q1303 VS2SC3928AR-1Y J 2SC3928AR AB
Q1304 VS2SA1530AR-1Y J 2SA1530AR AB
Q1501 VS2SC3928AR-1Y J 2SC3928AR AB
Q1701 VSDTC114EE/-1Y J DTC114EE AB
Q1703 VSHN1C01FU/-1Y J HN1C01FU AC
Q2001 VSRN1704///-1Y J RN1704 AC
Q2004 VS2SC3928AR-1Y J 2SC3928AR AB
Q2006 VSRN1704///-1Y J RN1704 AC
Q2007 VSDTC114EE/-1Y J DTC114EE AB
Q2551 VSDTC144EUA-1Y J DTC144EUA AB
Q2552 VSRN1704///-1Y J RN1704 AC
Q2553 VSRN1704///-1Y J RN1704 AC
Q2554 VSHN1B04FU/-1Y J HN1B04FU AC
Q3001 VSHN1C01FU/-1Y J HN1C01FU AC
Q3002 VSHN1C01FU/-1Y J HN1C01FU AC
Q3003 VSHN1C01FU/-1Y J HN1C01FU AC
Q3004 VSHN1C01FU/-1Y J HN1C01FU AC
Q3005 VSHN1C01FU/-1Y J HN1C01FU AC
Q3006 VSHN1B04FU/-1Y J HN1B04FU AC
Q3007 VSDTA114EE/-1Y J DTA114EE AB
Q3008 VS2SC3928AR-1Y J 2SC3928AR AB
Q3009 VSDTC114EE/-1Y J DTC114EE AB
Q3010 VSDTC114EE/-1Y J DTC114EE AB
Q3011 VSHN1B04FU/-1Y J HN1B04FU AC
Q3012 VS2SC3928AR-1Y J 2SC3928AR AB
Q3013 VSDTC114EE/-1Y J DTC114EE AB
Q3014 VSDTC114EE/-1Y J DTC114EE AB
Q3015 VSHN1B04FU/-1Y J HN1B04FU AC
Q3016 VS2SC3928AR-1Y J 2SC3928AR AB
Q3017 VSDTC114EE/-1Y J DTC114EE AB
Q3018 VSDTC114EE/-1Y J DTC114EE AB
Q3019 VSRN1704///-1Y J RN1704 AC
Q3503 VS2SC3928AR-1Y J 2SC3928AR AB
Q3504 VS2SC3928AR-1Y J 2SC3928AR AB
Q3505 VS2SC3928AR-1Y J 2SC3928AR AB
Q4002 VSHN1B04FU/-1Y J HN1B04FU AC
Q4003 VSHN1B04FU/-1Y J HN1B04FU AC
Q4004 VSHN1B04FU/-1Y J HN1B04FU AC
Q4005 VS2SC2735//-1Y J 2SC2735 AB
Q4006 VS2SC3928AR-1Y J 2SC3928AR AB
Q5001 VSHN1B04FU/-1Y J HN1B04FU AC
Q5003 VS2SC3928AR-1Y J 2SC3928AR AB
Q5005 VSHN1B04FU/-1Y J HN1B04FU AC
Q6001 VSDTC144EE/-1Y J DTC144EE AA
Q8001 VSRN4904///-1Y J RN4904 AB
Q8002 VSRN4904///-1Y J RN4904 AB
Q8201 VSHN1B04FU/-1Y J HN1B04FU AC
DIODES AND THERMISTER
D1501 VHDDAN202K/-1Y J Diode AB
D1701 VHDHSU119//-1Y J Diode AB
D1702 VHDHSU119//-1Y J Diode AB
D1703 VHDHSU119//-1Y J Diode AB
D1704 VHDHSU119//-1Y J Diode AB
D1705 VHDHSU119//-1Y J Diode AB
D1706 VHDHSU119//-1Y J Diode AB
D1710 VHDDAN202K/-1Y J Diode AB
D1712 VHDDAN202K/-1Y J Diode AB
D1713 VHDHSU119//-1Y J Diode AB
D1715 VHDHSU119//-1Y J Diode AB
D1716 VHDHSU119//-1Y J Diode AB
D1717 VHDHSU119//-1Y J Diode AB
D1718 VHDHSU119//-1Y J Diode AB
D2002 RH-EX1247CEZZY J Zener Diode, 5.6V AB
D2004 RH-EX1247CEZZY J Zener Diode, 5.6V AB
D2009 RH-EX1244CEZZY J Zener Diode, 5.1V AB
D2551 RH-PX0210TAZZY J Power Indicator AC
D2552 RH-PX0210TAZZY J Lamp Indicator AC
D2553 RH-PX0196TAZZY J Temperature AC
Warning Indicator
D2554 RH-EX0515CEZZY J Zener Diode AB
D2555 RH-EX0676CEZZY J Zener Diode AB
D3001 VHDKDS226//-1Y J Diode AB
D3002 VHDKDS226//-1Y J Diode AB
D3003 VHDKDS226//-1Y J Diode AB
D3301 RH-EX0515CEZZY J Zener Diode, 5.1V AB
D3302 RH-EX0515CEZZY J Zener Diode, 5.1V AB
D3501 RH-EX1262CEZZY J Zener Diode, 9.1V AB
D3502 RH-EX1247CEZZY J Zener Diode, 5.6V AB
D3503 RH-EX1247CEZZY J Zener Diode, 5.6V AB
D4001 RH-EX1247CEZZY J Zener Diode, 5.6V AB
D4002 RH-EX1247CEZZY J Zener Diode, 5.6V AB
D4003 RH-EX1247CEZZY J Zener Diode, 5.6V AB
D4004 RH-EX1247CEZZY J Zener Diode, 5.6V AB
D4005 VHDHSU119//-1Y J Diode AB
D4008 VHDKDS226//-1Y J Diode AB
D4009 VHDKDS226//-1Y J Diode AB
D4010 VHDKDS226//-1Y J Diode AB
D4011 VHDKDS226//-1Y J Diode AB
D4012 VHDKDS226//-1Y J Diode AB
D4013 VHDKDS226//-1Y J Diode AB
D4014 RH-EX1271CEZZY J Zener Diode, 12V AB
D4015 RH-EX1271CEZZY J Zener Diode, 12V AB
D4016 RH-EX1271CEZZY J Zener Diode, 12V AB
D4017 RH-EX1271CEZZY J Zener Diode, 12V AB
D5001 RH-EX1247CEZZY J Zener Diode, 5.6V AB
D5002 RH-EX1247CEZZY J Zener Diode, 5.6V AB
PACKAGED CIRCUITS
X2001 RCRSC0141TAZZY J Crystal, 14.7456MHz AG
X3001 RCRSC0012CEZZY J Crystal, 20.25MHz AH
X8001 RCRUAA013WJZZY J Crystal, 133MHz AP
X8002 RCRUAA018WJZZY J Crystal, 43MHz AL
COILS
L1101 VPCKM100J1R3NY J Peaking 10µH AB
L1201 VPCKM100J1R3NY J Peaking 10µH AB
L1301 VPCKM100J1R3NY J Peaking 10µH AB
L3004 VPCKM100J1R3NY J Peaking 10µH AB
