Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
132
PG-B10S
CABINET AND MECHANICAL PARTS
1 CBDYFA001WJ01 J Front Body Ass’y AQ
1-1 Not Available – Front Body —
1-2 GCOVAA419WJSA J RC Cover AD
1-3 PCOVZA017WJZZ J RC Filter Cover AD
1-4 PSLDCA013WJFW J RC Shield B AF
1-5 PZETKA062WJKZ J Insulating Spacer R AC
2 CBDYTA041WJ01 J Top Body Ass’y Unit AY
2-1 DBDYTA041WJ01 J Top Body Ass’y AW
2-1-1 Not Available – Top Body —
2-1-2 GCOVAA541WJSA J LED Decoration Cover AC
2-1-3 JBTN-A205WJSA J Control Button AM
2-1-4 QEARPA078WJFW J Panel Shield AF
3 CBDYUA041WJ01 J Bottom Body Ass’y Unit BN
3-1 DBDYUA041WJ01 J Bottom Body Ass’y AX
3-1-1 Not Available – Bottom Body —
3-1-2 GCOVAA664WJK0 J Side Cover AD
3-1-3 LX-NZ3120CEFW J Insert Nut(M5), x1 AB
3-1-4 LX-NZ3144CEFW J Insert Nut(M4), x3 AC
3-1-5 LX-NZA014WJFW J Insert Nut(M3), x2 AC
3-1-6 PFiLDA006WJZZ J Bottom Filter AE
3-2 CCOVAA485WJ01 J Lamp Cover Ass’y AK
3-2-1 Not Available – Lamp Cover —
3-2-2 LX-BZ3449CEF9 J Screw, x1 AD
3-2-3 XREUW20-04000 J E-ring, x1 AA
3-3 CCOVAA486WJ01 J Exhaust Cover Ass’y AP
3-3-1 Not Available – Exhaust Cover —
3-3-2 HPNC-A028WJSA J Punching Net AK
3-3-3 NFANRA023WJZZ J Cooling Fan AW
3-3-4 XEBSN40P12000 J Screw, x2 AB
3-4 CHLDZA252WJ01 J Intake Holder Ass’y AL
3-4-1 Not Available – Intake Holder —
3-4-2 LX-BZ3449CEF9 J Screw AD
3-4-3 PFiLDA009WJZZ J Intake Filter AC
3-4-4 XREUW20-04000 J E-ring, x1 AA
3-5 GLEGPA020WJKA J Front Adjustment Foot AT
3-6 GLEGPA021WJSA J Rear Foot(R) AD
3-7 GLEGPA023WJSA J Rear Adjustment Foot AF
3-8 LANGFA062WJFW J Kensington Security AE
Standard Connector
3-9 LX-HZ3105CEFN J Screw, x2 AB
3-10 LX-NZ3095CEFN J Screw(M5), x1 AB
3-11 NFANSA012WJZZ J Intake Fan AV
3-12 PCOVAA025WJKZ J Speaker Spacer AD
3-13 PDUC-A033WJKZ J Intake Duct AH
3-14 PSPAH0648CE00 J Adjuster Spacer AB
3-15 PSPAT0020CEZZ J Tape AD
3-16 QCNW-B746WJZZ J Leaf Switch AK
3-17 RSP-ZA029WJZZ J Speaker AQ
3-18 XEBSN30P12000 J Screw, x5 AA
3-19 XEPSN40P12000 J Screw, x1 AB
4 CCAPHA004WJ01 J Lens Cap AK
5 Refer to Optical Mechasnism Unit
6 Not Available – POWER/BALLAST —
Unit Holder Ass’y
6-1 PSLDMA264WJFW J POWER/BALLAST AN
Unit Holder
6-2 LHLDFA011WJKZ J POWER/BALLAST AC
Holder, x6
6-3 LHLDW1226CEZZ J Main Clip AC
6-4 LX-LZ1011GE00 J Clip AC
6-5 NFANR0140CEZZ J Cooling Fan BB
6-6 PZETKA048WJKZ J POWER/BALLAST Shield AF
6-7 XBBSN30P10000 J Screw, x2 AA
7 DUNTKC053FE01 J MAIN Unit CQ
8 DUNTKC054DE01 J POWER Unit BQ
9 DUNTKC055DE01 J AC-INLET Unit AX
DUNTKC055DE01
AC INLET UNIT
VARISTOR
å VA701 RH-VXA018WJZZ J Varistor AD
COIL
å L701 RCiLFA057WJZZ J Filter Coil AG
CAPACITORS
å C701 RC-FZ038SCEZZ J 0.47 250V Film AE
å C702 RC-KZ0105GEZZ J 2200p 250V Ceramic AD
å C703 RC-FZ038SCEZZ J 0.47 250V Film AE
å C704 RC-KZ0105GEZZ J 2200p 250V Ceramic AD
RESISTOR
R702 RR-HZ0122CEZZY J 470k Resistor
MISCELLANEOUS PARTS
å F701 QFS-C5023CEZZ J Fuse, T5AH/250V AD
FH701 QFSHD1013CEZZ+ J Fuse Holder AC
FH702 QFSHD1014CEZZ+ J Fuse Holder AC
å P701 QPLGN0297CEZZ J Plug, 2-pin(BA) AB
å SC701 QSOCAA005WJZZ J AC Socket AF
QCNW-B898WJZZ J Connecting Cord AD
LANGKA192WJFW J AC Inlet Angle AG
LX-BZA044WJFU J Screw, x2 AA
LX-BZ3270CEFN J Screw, x2 AA
