Sharp PG-B10S User Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
131
PG-B10S
DUNTKC054DE01
POWER UNIT
INTEGRATED CIRCUITS
IC711 VHiMZ1540++-1 J MZ1540-4109F02 AW
IC721 VHiMR2920++-1 J MR2920 AQ
å IC722 RH-FXA003WJZZ J PC123Y82 AD
å IC723 RH-FXA003WJZZ J PC123Y82 AD
IC741 VHiHA17431U-1Y J HA17431UA-TL AE
TRANSISTORS
Q722 VS2SC3928AR-1Y J 2SC3928AR AB
Q724 VS2SA1530AR-1Y J 2SA1530AR AB
Q741 VSDTC114EKA-1Y J DTC114EKA AB
DIODES
å D711 RH-DX0476CEZZ J Diode AG
D712 RH-DXA024WJZZY J Diode AE
D713 RH-EX1294CEZZY J Zener Diode, 27V AB
D714 RH-EX1294CEZZY J Zener Diode, 27V AB
D715 RH-EX1254CEZZY J Zener Diode, 6.8V AB
D716 RH-EX1254CEZZY J Zener Diode, 6.8V AB
D721 VHDHSU119//-1Y J Diode AB
D722 RH-EX1280CEZZY J Zener Diode, 16V AB
D724 RH-EX1241CEZZY J Zener Diode AB
D725 RH-EX1294CEZZY J Zener Diode, 27V AB
D726 VHDD1FL20U/-1Y J Diode AC
D727 VHDD1FL20U/-1Y J Diode AC
D728 VHD05NU42//-1Y J Diode AD
D741 VHDD1FL20U/-1Y J Diode AC
D742 RH-DXA027WJZZY J Diode AE
D743 RH-DX0459CEZZ J Diode AE
D744 RH-EXA105WJZZY J Zener Diode AE
D745 RH-EXA105WJZZY J Zener Diode AE
å TH711 RH-HXA012WJZZ J Thermister AE
COILS
L711 RCiLPA159WJZZ J Peaking Coil AE
TRANSFORMER
å T711 RCiLCA066WJZZ J Choke Coil AN
å T721 RTRNWA111WJZZ J Transformer AK
CAPACITORS
C711 RC-FZA123WJZZ J 1 450V Film AF
C712 RC-FZA124WJZZ J 2.2 450V Film AG
C713 VCCCTV1HH102JY J 1000p 50V Ceramic AB
C714 VCKYTV1EB474KY J 0.47 25V Ceramic AC
C715 VCEA4A1VN107M+ J 100 35V Electrolytic AC
C716 RC-EZA215WJZZ J 120 420V Electrolytic AL
C718 RC-FZA126WJZZ J 0.1 450V Film AE
C721 RC-KZ0103GEZZ J 1000p 250V Ceramic AD
C722 RC-KZ0103GEZZ J 1000p 250V Ceramic AD
C723 VCKYTV1HB472KY J 4700p 50V Ceramic AA
C725 VCKYTV1EB224KY J 0.22 25V Ceramic AA
C726 VCKYTV1EB104KY J 0.1 25V Ceramic AB
C727 VCEA4A1VN107M+ J 100 35V Electrolytic AC
C729 VCCCTV1HH101JY J 100p 50V Ceramic AA
C733 RC-KZA065WJZZ J 470p 2kV Ceramic AC
C734 VCEA4A1VN107M+ J 100 35V Electrolytic AC
C741 VCKYTV1EB104KY J 0.1 25V Ceramic AB
C742 VCEA0A1CW476M+ J 47 16V Electrolytic AB
C743 RC-EZ1208CEZZ J 2200 10V Electrolytic AD
C744 RC-EZ1233CEZZ J 470 25V Electrolytic AD
C745 RC-EZ1241CEZZ J 2200 25V Electrolytic AE
C747 VCKYTV1EB104KY J 0.1 25V Ceramic AB
C748 VCEA0A1CW226M+ J 22 16V Electrolytic AB
C749 VCKYPA2HB471K+ J 470p 500V Ceramic AA
C750 VCKYPA2HB102K+ J 1000p 500V Ceramic AA
C751 VCKYPA2HB102K+ J 1000p 500V Ceramic AA
C752 VCKYTV1EB104KY J 0.1 25V Ceramic AB
RESISTORS
R711 VRS-TW2ED221JY J 220 1/4W Metal Oxide AB
R712 VRS-TW2ED223JY J 22k 1/4W Metal Oxide AA
R714 VRN-VV3DBR27J J 0.27 2W Metal Film AB
R715 VRN-VV3DBR27J J 0.27 2W Metal Film AB
R716 VRS-TQ2BD472JY J 4.7k 1/8W Metal Oxide AA
R717 VRN-RL3DBR18J+ J 0.18 2W Metal Film AB
R721 VRS-TQ2BD223JY J 22k 1/8W Metal Oxide AA
R722 VRS-TQ2BD243JY J 24k 1/8W Metal Oxide AA
R723 VRS-TW2ED103JY J 10k 1/4W Metal Oxide AA
R726 VRS-TW2ED103JY J 10k 1/4W Metal Oxide AA
R727 VRS-TQ2BD103JY J 10k 1/8W Metal Oxide AA
R728 VRS-TQ2BD103JY J 10k 1/8W Metal Oxide AA
R731 VRS-SV2HC100J J 10 1/2W Metal Oxide AA
R733 VRN-TV1JD513DY J 51k 1/16W Metal Film AA
R735 VRS-TW2ED103JY J 10k 1/4W Metal Oxide AA
R736 VRN-VV3DBR10J J 0.1 2W Metal Film AB
R737 VRS-TQ2BD563JY J 56k 1/8W Metal Oxide AA
R738 VRS-SV2HC221JY J 220 1/2W Metal Oxide AB
R739 VRN-SV2HC1R0JY J 1 1/2W Metal Film AB
R741 VRS-TQ2BD000JY J 00 1/8W Metal Oxide AA
R742 VRS-TQ2BD470JY J 47 1/8W Metal Oxide AA
R743 VRN-TV1JD272DY J 2.7k 1/16W Metal Film AA
R744 VRN-TV1JD391DY J 390 1/16W Metal Film AA
R745 VRS-TQ2BD103JY J 10k 1/8W Metal Oxide AA
R746 VRS-TW2ED331JY J 330 1/4W Metal Oxide AB
R747 VRN-TV1JD222DY J 2.2k 1/16W Metal Film AB
R748 VRS-TW2ED101JY J 100 1/4W Metal Oxide AA
R749 VRS-TQ2BD000JY J 00 1/8W Metal Oxide AA
R750 VRS-TW2ED101JY J 100 1/4W Metal Oxide AA
R751 VRS-TQ2BD102JY J 1k 1/8W Metal Oxide AA
R752 VRS-TQ2BD102JY J 1k 1/8W Metal Oxide AA
R753 VRS-TW2ED103JY J 10k 1/4W Metal Oxide AA
MISCELLANEOUS PARTS
FB721 RBLN-0094CEZZY J Ferrite Bead AC
FB722 RBLN-1039CEZZY J Ferrite Bead AC
FB741 RBLN-0094CEZZY J Ferrite Bead AC
FB742 RBLN-0094CEZZY J Ferrite Bead AC
FB743 RBLN-0094CEZZY J Ferrite Bead AC
FB744 RBLN-0036CEZZY J Ferrite Bead AB
P711 QPLGN0297CEZZ J Plug, 2-pin(BA) AB
P712 QPLGN0269GEZZ J Plug, 2-pin(PL) AB
P741 QPLGN0324FJZZ J Plug, 22-pin(EA) AD
P742 QPLGN0578GEZZ J Plug, 5-pin(D) AB
RMC741 RRMCU0237CEZZ J R/C Receiver AF
PRDARA085WJFW J Heat Sink AG
PSLDCA014WJFW J Shield AE
QCNW-B745WJQZ J Connecting Cord AM
LANGQA012WJFW J Angle AC
LX-BZ3049GEFN J Screw, x2 AD
