Sharp PG-B10S User Manual

25
PG-B10S
ELECTRICAL ADJUSTMENT
1 EEPROM
initialization
1. Turn on the power (with the
lamp on) and warm up the
set for 15 minutes.
» Make the following settings.
Press S2002 to call the process mode and execute
"SS2" on SS menu.
2-1 R/G/B Bright-
ness adjustment
1. Select the following group
and subjects.
Group : AD
Subject : R-Bright
G-Bright
B-Bright
(Process GAMMA interlock)
2. Feed the SVGA 16-step sig-
nal with an amplitude level
of 50% (0.35 Vp-p).
1.Check the setting valve.
R/G/B-Bright: 63
No. Adjusting point Adjusting conditions Adjusting procedure
2-2 R/G/B Contrast
adjustment
1. Select the following group
and subjects.
Group : AD
Subject : R-Contrast
G-Contrast
B-Contrast
(Process GAMMA interlock)
2. Feed the SVGA white sig-
nal with an amplitude level
of 96% (0.67 Vp-p).
1.Watching the screen, adjust the R-, G- and B-Con-
trast settings so that because of some pixel drop-
outs, the bright color zone should become just about
a half.
3 DTV Brightness/
Contrast adjust-
ment
1. Feed a 480P component
10-step signal with 100%
amplitude.
2. Select the following group
and subjects.
Group : DTV
Subject : Bright
Contrast
(Process GAMMA interlock)
1. Check the setting value.
Contrast (White Level): 45
Bright (Black Level): 32
4 DVD Brightness/
Contrast adjust-
ment
1. Feed a 480I component 10-
step signal with 100%
amplitude.
2. Select the following group
and subjects.
Group : DVD
Subject : Bright
Contrast
(Process GAMMA interlock)
1. Check the setting value.
Contrast (White Level): 46
Bright (Black Level): 34
