Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
122
PG-B10S
ERSATZTEILLISTE
AUSTAUSCH VON TEILEN
Ersatzteile, die besondere Sicherheitseigenschften haben, sind in
dieser Anleitung markiert. Elektrische Komponenten mit solchen
Eigenshaften sind in den Ersatzteil durch "å" gekenn-zeichnet.
Der Gebrauch von Ersatzteilen, die nicht deselben Sicherheits-
eigenschaften haben wie die vom Hersteller empfohlenen ud in der
Bedienungsanleitung angegebenen, können zur Ursache von
Blitzeinschlägen, Bränden und anderen Gefahren werden.
WIE MAN ERSATSTEILE BESTELLT
Damit Ihre Bestellung promt und korrekt ausgeführt wird, geben Sie
bitte folgende Informationen.
1. MODELL NR. 2. REF. NR.
3. ERSATZTEIL NR. 4. BESCHREIBUNG
5. KODE 6. QUANTITÄT
Ref. No. Part No. ★ Description Code
Ref. No. Part No. ★ Description Code
PRINTED WIRING BOARD ASSEMBLIES
DUNTKC053FE01
MAIN UNIT
DUNTKC053FE01 J MAIN Unit CQ
DUNTKC054DE01 J POWER Unit BD
DUNTKC055DE01 J AC INLET Unit AX
RDENCA050WJZZ J BALLAST Unit BR
PARTS LIST
PARTS REPLACEMENT
Parts marked with "å" are important for maintaining the safety of
the set. Be sure to replace these parts with specified ones for main-
taining the safety and performance of the set.
HOW TO ORDER REPLACEMENT PARTS
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
5. CODE 6. QUANTITY
in USA: Contact your nearest SHARP Parts Distributor.
For location of SHARP Parts Distributor,
Please call Toll-Free; 1-800-BE-SHARP
in CANADA: Contact SHARP Electronics of Canada Limited
Phone (416) 890-2100.
★ MARKIERUNG : ERSATZTEILE-LIEFERUNG★ MARK: SPARE PARTS-DELIVERY SECTION
INTEGRATED CIRCUITS
IC1101 VHiL3E06100-1Q J L3E06100D0A BA
IC1102 VHiNJM2902V-1Y J NJM2902V AD
IC1103 VHiNJM2902V-1Y J NJM2902V AD
IC1104 VHiNJM2904V-1Y J NJM2904V AF
IC1201 VHiL3E06100-1Q J L3E06100D0A BA
IC1204 VHiNJM2904V-1Y J NJM2904V AF
IC1301 VHiL3E06100-1Q J L3E06100D0A BA
IC1401 VHiL3E07070-1Q J L3E07070K0A BB
IC1402 VHiPST600iM-1Y J IC-PST600IMT AE
IC1403 VHiSNAHC14H-1Y J SN74AHC2G14HDC AE
IC1501 VHiNJM2902V-1Y J NJM2902V AD
IC1503 VHiM62393FP-1Y J M62393FP AK
IC1505 VHiTC4W53U/-1Y J TC4W53FU AF
IC1701 VHiPQ050DZ1-1Y J PQ050DZ01Z AE
IC1702 VHiPQ050DZ1-1Y J PQ050DZ01Z AE
IC1703 VHiPQ033DZ1-1Y J PQ033DZ01ZP AE
IC1704 VHiSi3025LA-1Y J SI-3025LSA-TL AF
IC1705 VHiPQ033DZ1-1Y J PQ033DZ01ZP AE
IC1706 VHiPQ20WZ11-1Y J PQ20WZ1U AF
IC1707 VHiPQ018EZ5-1Y J PQ018EZ5MZP AF
IC1708 VHiPQ20WZ11-1Y J PQ20WZ1U AF
IC1713 VHiPQ20WZ11-1Y J PQ20WZ1U AF
IC1714 VHiPQ20WZ11-1Y J PQ20WZ1U AF
IC1715 VHiPQ20WZ11-1Y J PQ20WZ1U AF
IC1716 VHiPQ033DZ1-1Y J PQ033DZ01ZP AE
IC2002 VHiTE7780++-1Q J TE7780 AW
IC2006 VHiSP3220E+-1Y J SP3220ECY/TR AM
IC2007 VHiAHCT08PW-1Y J SN74AHCT08PW AD
IC3001 VHiVPC3230D1EQ J VPC3230D-QA-B3 BD
IC3003 VHiCXA1839Q-1 J CXA1839 AZ
IC3301 VHiDA7056AT-1Y J TDA7056AT/N2 AM
IC4001 RH-iXA848WJZZS J I.C. AK
IC4002 VHiLMH6683T-1Y J LµH6683MTX AQ
IC5001 VHiSNT1G08C-1Y J SN74AHCT1G08DC AD
IC5002 VHiSNT1G08C-1Y J SN74AHCT1G08DC AD
IC5003 VHiSNT1G08C-1Y J SN74AHCT1G08DC AD
IC5004 VHiSNT1G08C-1Y J SN74AHCT1G08DC AD
IC5005 VHiNJM2901V-1Y J NJM2901V AE
IC5006 VHiLV123AT+-1Y J SN74LV123APWR AF
IC5007 VHiSN1G00DC-1Y J SN74AHC1G00HDC AD
IC5008 VHiSN1G32DC-1Y J SN74AHC1G32HDC AD
