No. Adjusting point Adjusting conditions Adjusting procedure
29
PG-B10S
1. Select OFF from the process mode.
Make sure the off-timer starts with 5 minutes
onscreen and count one minute in one second.
And then indication is 0 minute, the power supply
of the set is cut off.
24 Off-timer per-
formance
1. Heat the thermistor with a
hair dryer.
1. Make sure that the temperature is indicated.25 Thermistor
performance
checking
1. Make the following settings.
Process adjustment Remote control adjustment
SS3 Factory setting at 3
27 Delivery set-
tings
1. Feed the phase check pat-
tern signal.
1. In the VGA, SVGA and XGA modes, make sure the
Clock, Phase, H-Pos and V-Pos settings can be au-
tomatically adjusted.
26 Auto sync
performance
checking
No. Adjusting point Adjusting conditions Adjusting procedure
22 RGB tone
reproduction
adjustment
1. Make sure the 100% and 95% white as well as the
0% and 5% black gradations are visible.
1. Feed the SMPTE pattern
signal.
23 White balance
checking
1. Use the adjustment condi-
tions in the item 10 for RGB
input and item 11 for sRGB
input.
Check that there is no deviation of white balance with
the monitor.
21 Sample hold
pulse phase
checking
1. Check the fixed value.
GCK-PHASE :282
RCK-PHASE :282
BCK-PHASE :282
1. Feed the SVGA 75-Hz
black signal.
2. Select the following group
and subjects.
Group : OUTPUT3
Subject : GCK-PHASE
RCK-PHASE
BCK-PHASE
To Next Page
