Sharp PN-L702B Specifications

General

Pixel pitch	0.802 x 0.802 mm
Aspect ratio	16:9
Screen shape	Flat
Response time	6 ms
Composite sync	Yes
Display diagonal	60 \
Display brightness	300 cd/m²
Display technology	LCD
Contrast ratio (typical)	3000:1
Display number of colors	1.073 billion colors
Viewing angle, horizontal	160 °
Certification	UL 60950, FCC
Product color	Black
Bezel width	41 mm
Placement supported	Horizontal
Ethernet LAN (RJ-45) ports	1
Display viewable area (HxV)	1538.2875 x 865.1875 mm
Number of products included	1 pc(s)
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	240 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Package weight	82100 g
Camera included	No
RMS rated power	14 W
Number of speakers	2

Weight and Dimensions

Depth (without stand)	115.8875 mm
Width (without stand)	1647.825 mm
Height (without stand)	982.6625 mm
Weight (without stand)	70000 g
