Sharp PN-L702B - RS-232 C Command Reference: Power & Input

36
E
RS-232C command table
How to read the command table
Command: Commandeld(Seepage32.)
Direction: W Whenthe“Parameter”issetintheparametereld(seepage32),thecommandfunctionsasdescribed
under“Control/ResponseContents”.
R The returned value indicated under “Reply” can be obtained by setting “????”, “
?”or“???+”
(repeatercontrol)intheparametereld(seepage32).
Parameter: Parametereld(Seepage32.)
Reply: Response(Returnedvalue)
*1:
“●”indicatesacommandwhichcanbeusedinpowerstandbymoderegardlessoftheSTANDBYMODEsetting.
“○”indicatesacommandwhichcannotbeusedinpowerstandbymodewhenSTANDBYMODEissettoLOWPOWER.
“–”indicatesacommandwhichcannotbeusedinpowerstandbymoderegardlessoftheSTANDBYMODEsetting.
*2: PN-ZB01(optional)limitations
 (A)WhenPN-ZB01(optional)isnotattached,(B)WhenPN-ZB01(optional)isattached.
 ○:Thecommandcanbeused.
 - :Error(ERR)
Power control/Input mode selection
Function Command Direction Parameter Reply Control/Response contents *1
*2
(A) (B)
POWERCONTROL POWR W 0 Switches to standby mode.
● ○ ○
1 Returns from standby mode.
R 0 Standby mode
1 Normal mode
2 Input signal waiting mode
INPUTMODESELECTION INPS W 0 Togglechangeforinputmode.TerminalsnotselectedinINPUTSELECT
cannot be selected.
●
○ ○
1 PCDVI-D
“ERR”whenAVDVI-DisselectedforDVIofINPUTSELECT.
-
○
2 PCD-SUB
“ERR”whenotherthanPCD-SUBisselectedforD-SUBofINPUTSELECT.
○ ○
3 AVCOMPONENT(BNC)/AVCOMPONENT(D-SUB)
“ERR”whenotherthanPCRGBisselectedforBNCofINPUTSELECT,and
whenotherthanAVCOMPONENTisselectedforD-SUBofINPUTSELECT.
○ ○
4 AVVIDEO(BNC)/AVVIDEO(D-SUB)
○ ○
6 PCRGB
“ERR”whenAVCOMPONENTisselectedforBNCofINPUTSELECT.
-
○
7 AVDVI-D
“ERR”whenPCDVI-DisselectedforDVIofINPUTSELECT.
-
○
8 AVS-VIDEO -
○
9 AVHDMI
“ERR”whenPCHDMIisselectedforHDMIofINPUTSELECT.
○ ○
10 PCHDMI
“ERR”whenAVHDMIisselectedforHDMIofINPUTSELECT.
○ ○
R 1 PCDVI-D
● ○ ○
2 PCD-SUB
3 AVCOMPONENT
4 AVVIDEO
6 PCRGB
7 AVDVI-D
8 AVS-VIDEO
9 AVHDMI
10 PCHDMI
Controlling the Monitor with a PC (RS-232C)
