Sharp PN-L702B User Manual

9
E
Forinformationonthetouchpaneldriver,seetheTouchPanelDriverOperationManual.ForinformationonthePenSoftware,
see the Pen Software Operation Manual.
Supplied Components
If any component should be missing, please contact your dealer.

LiquidCrystalDisplayMonitor:1

Remotecontrolunit:1

Cableclamp:2

Powercord:1

R-6battery(“AA”size):2

CD-ROM(UtilityDiskforWindows):1

SetupManual:1

Touchpen:1
* SharpCorporationholdsauthorshiprightstotheUtilityDiskprogram.Donotreproduceitwithoutpermission.
* Forenvironmentalprotection!
 Donotdisposeofbatteriesinhouseholdwaste.Followthedisposalinstructionsforyourarea.

Pentip(fortouchpen):2

Touch pen battery
(LR-03(“AAA”size)):1

USBcable:1

Eraser:1

Tray:1

Traymountingtting
(cover/bracket):x2
System Requirements
To use the touch panel, the touch panel must be connected to a computer, and the touch panel driver and Pen Software must be
installedonthecomputerfromthesuppliedCD-ROM.Systemrequirementsforeachsoftwareprogramareasfollows.
Computer
PC/ATcompatiblecomputerwithaUSB1.1port(mustbeabletosupplya500mA(5.0V)current)
andabletooutputaresolutionof1920x1080.(CD-ROMdriverequiredforsoftwareinstallation.)
OS
WindowsXP(32-bitor64-bitversion),WindowsVista(32-bitor64-bitversion),Windows7(32-bit
or64-bitversion)
CPU
IntelCeleronorAMDSempron1.6GHzorfaster
IntelCore2DuoorAMDAthlonIIX22.8GHzorfasterrecommended
Memory Atleast2GB(atleast1GBforWindowsXP)
Freespaceonharddrive Atleast100MB(freespaceseparatelyrequiredfordatastorage)
Toconnectthetouchpanelandinstallthetouchpaneldriver,seetheTouchPanelDriverOperationManual.
To install the Pen Software, see the Pen Software Operation Manual.
Contents
IMPORTANT INFORMATION ............................................3
DEAR SHARP CUSTOMER ..............................................5
SAFETY PRECAUTIONS ..................................................5
TIPS AND SAFETY INSTRUCTIONS ...............................7
MOUNTING PRECAUTIONS ............................................8
Supplied Components .....................................................9
System Requirements .....................................................9
Part Names .....................................................................10
Connecting Peripheral Equipment ...............................12
ConnectionwithaPCorAVequipment .....................12
ConnectionwhenthePN-ZB01(optional)
is attached .................................................................13
Connecting the Power Cord .........................................14
Binding Cables ...............................................................14
Removing the Handles ..................................................14
Preparing the Remote Control Unit ..............................15
Installing the batteries ................................................15
Remote control operation range .................................15
Turning Power On/Off ....................................................16
Turning on the main power.........................................16
Turning power on/off ..................................................16
Disablingpoweron/offoperations ..............................17
Touch Pen Preparations/Touch Action ........................18
Inserting the battery ...................................................18
Touch action and touch mode ....................................18
Touch action ...............................................................18
Other functions ...........................................................20
Cautionarypoints .......................................................20
Eraser .........................................................................20
Basic Operation .............................................................21
Menu Items .....................................................................23
Displayingthemenuscreen .......................................23
Menu item details .......................................................24
AdjustmentsforPCscreendisplay ............................30
Initialization (Reset)/Functional Restriction Setting
(FUNCTION) ....................................................................31
Controlling the Monitor with a PC (RS-232C) ..............32
PCconnection ............................................................32
Communicationconditions .........................................32
Communicationprocedure .........................................32
SettingoftheGAMMAuserdata ................................35
RS-232Ccommandtable ...........................................36
Controlling the Monitor with a PC (LAN) .....................43
Settings to connect to a LAN ......................................43
ControllingwithaPC ..................................................45
Troubleshooting .............................................................51
Specications ...............................................................53
Mounting Precautions
(For SHARP dealers and service engineers) ...............57

Traymountingscrews:M5x4/M4x2

Terminallabel:1
Used when installing the interface
expansionboardPN-ZB01(optional).

CoverSharplogo:1
Place this sticker onto the SHARP logo to
cover the logo.

Sharp PN-L702B Specifications

General

Pixel pitch	0.802 x 0.802 mm
Aspect ratio	16:9
Screen shape	Flat
Response time	6 ms
Composite sync	Yes
Display diagonal	60 \
Display brightness	300 cd/m²
Display technology	LCD
Contrast ratio (typical)	3000:1
Display number of colors	1.073 billion colors
Viewing angle, horizontal	160 °
Certification	UL 60950, FCC
Product color	Black
Bezel width	41 mm
Placement supported	Horizontal
Ethernet LAN (RJ-45) ports	1
Display viewable area (HxV)	1538.2875 x 865.1875 mm
Number of products included	1 pc(s)
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	240 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Package weight	82100 g
Camera included	No
RMS rated power	14 W
Number of speakers	2

Weight and Dimensions

Depth (without stand)	115.8875 mm
Width (without stand)	1647.825 mm
Height (without stand)	982.6625 mm
Weight (without stand)	70000 g
