Dimensional Drawings
Note that the values shown are approximate values.
4-9/16
[116]
Unit: inch [mm]
7-7/8
[200]
7-7/8
[200]
3-15/16
[100]
3-15/16
[100]
7-7/8 [200]
VESA holes *
59-9/16 [1513]
Opening width (61-11/16 [1567])
Opening height (35-1/2 [901])
64-7/8 [1648]
1-7/8 [47]
38-11/16 [982]
39-7/8 [1013]
41 [1041]
2-3/16
[56]
3-5/8
[92.5]
 Whenmountingthemonitor,besuretouseawall-mountbracketthatcomplieswiththeVESA-compatiblemountingmethod.
SHARP recommends using M6 screws and tighten the screws.
Notethatscrewholedepthofthemonitoris3/8inch(10mm).Loosemountingmaycausetheproducttofall,resultingin
seriouspersonalinjuriesaswellasdamagetotheproduct.Thescrewandholeshouldcometogetherwithover5/16inch
(8mm)lengthofthread.UseabracketwhichhasbeenapprovedforUL1678standard,andwhichcanendureatleast4times
or more the weight of the monitor.
n
Power management
ThismonitorconformstoVESADPMSandDVIDMPM.Bothyourvideocardandcomputermustsupportthesamestandardin
order for the monitor’s power management function to work.
DPMS:DisplayPowerManagementSignaling
DPMS Screen
Power
consumption
Hsync Vsync
ONSTATE Display 235W*
1
Yes Yes
STANDBY
No
display
1.0W*
1
*
2
No Yes
SUSPEND Yes No
OFFSTATE No No
*1 WhenPN-ZB01(optional)isnotconnected.
*2 WhenAUTOINPUTCHANGEissettoOFF.
DMPM:DigitalMonitorPowerManagement
DMPM Screen
Power
consumption
Monitor ON Display 235W*
1
ActiveOFF No display 1.0W*
1
*
2
n
DDC (plug and play)
ThemonitorsupportstheVESADDC(DisplayDataChannel)standard.
DDCisasignalstandardforplugandplaybetweenmonitorsandcomputers.Informationaboutresolutionandotherparameters
isexchangedbetweenthetwo.ThisfunctioncanbeusedifthecomputersupportsDDCandithasbeenconguredtodetect
plug-and-playmonitors.
ThereareseveraltypesofDDC,dependingonthecommunicationmethodused.ThismonitorsupportsDDC2B.
