R-775(W)R-785(AL) - 42
∆
∆
∆
∆
Note: The parts marked "∆" may cause undue microwave exposure. / The parts marked "*" are used in
voltage more than 250V. / "§" Mark: Spare parts delivery section
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
OVEN PARTS
4- 1 DOVN-A022URK0 U Oven cavity 1 BG
4- 2 LBNDKA107WRP1 U Capacitor holder 1 AD
4- 3 FDUC-A003URY0 U Air duct assembly 1 AL
4- 4 LANGQA005URP0 U Air separate angle B 1 AC
4- 5 PDUC-A636WRP1 U Air guide duct 1 AM
4- 6 PFILWA001URP0 U Lamp filter 1 AB
4- 7 PHOK-A002URF1 U Latch hook 1 AH
4- 8 LANGQA014URP0 U Turntable motor angle 1 AE
4- 9 PSKR-A308WRF0 U Rear barrier 1 AH
4-10 FANGTA003URY0 U Turntable motor shaft assembly 1 AL
4-11 PPACGA002URE0 U Seal packing 1 AB
4-12 NFANJA038WRE0 U Fan blade 1 AF
4-13 PDUC-A637WRF2 U Fan duct 1 AL
4-14 PDUC-A008URP0 U Exhaust duct 1 AK
4-15 GCOVHA001URP1 U Bottom heater cover 1 AM
4-16 LANGFA155WRP7 U Chassis support 1 AF
4-17 PPACGA001URE0 U Heater packing 1 AD
4-18 LANGQA008URP0 U Grill heater angle 2 AD
4-19 PCUSUA019URE0 U Cushion 1 AA
4-20 PSPAGA001WRE0 U Vibration proof cushion 1 AA
4-21 PCUSUA012URE0 U Cushion 1 AB
4-22 PCOVQA002URP0 U Heater cover 2 AD
4-23 PCOVPA308WRE1 U Waveguide cover 1 AE
4-24 PDUC-A606WRF1 U Air intake duct 1 AK
DOOR PARTS
5 CDORFW023URK0 U Door assy [R-775(W)] 1 BG
5 CDORFA088URK0 U Door assy [R-785(AL)] 1 BG
5- 1 DDORFA766WRK0 U Door panel assembly 1 BE
5- 2 GWAKPW041URR0 U Door frame [R-775(W)] 1 AU
5- 2 GWAKPA103URR0 U Door frame [R-785(AL)] 1 AU
5- 3 LSTPPA017URF0 U Latch head 1 AG
5- 4 LHLD-A012URF0 U Glass holder 1 AB
5- 5 MSPRTA197WREZ U Latch spring 1 AC
5- 6 PGLSPA027URE0 U Front door glass 1 AN
5- 7 JHNDPW002URF0 U Door handle A [R-775(W)] 1 AK
5- 7 JHNDPA012URT0 U Door handle A [R-785(AL)] 1 AK
5- 8 JHNDPW003URF0 U Door handle B [R-775(W)] 1 AR
5- 8 JHNDPA013URT0 U Door handle B [R-785(AL)] 1 AR
5- 9 XETSD40P30000 U Screw: 4mm x 30mm 2 AA
5-10 XEBSD30P08000 U Screw: 3mm x 8mm 3 AA
5-11 XEBSD30P06000 U Screw: 3mm x 6mm 4 AA
5-12 GCOVHA365WRF3 U Choke cover 1 AM
MISCELLANEOUS
6- 1 FAMI-A072WRK2 U High rack 1 AT
6- 2 FAMI-A095WRK1 U Low rack 1 AR
6- 3 LHLDKA008WRF1 U P-clip 1 AA
6- 4 CTNT-A005URK0 U Turntable tray 1 AY
6- 5 FW-VZA061URE1 U Stop switch harness 1 AE
6- 6 TCAUHA006URR0 U Caution label 1 AE
6- 7 QW-QZA210WRE2 U High voltage wire B 1 AD
6- 8 FW-VZA097URE1 U Main harness 1 AX
6- 9 TLABMA203URR0 U Menu label 1 AD
6-10 TINS-A289URR0 U Operation manual 1 AS
6-11 TINS-A290URR0 U Quick start guide 1 AD
SCREWS,NUTS AND WASHERS
7- 1 XHPSD40P08K00 U Screw: 4mm x 8mm 1 AA
7- 2 LX-NZ0061WRE0 J M4 Flange nut 4 AA
7- 3 XWWSD50-06000 U Washer: 5mm x 0.6mm 1 AA
7- 4 XOTSE40P10000 U Screw: 4mm x 12mm 4 AA
7- 5 XHPSD40P06000 J Screw: 4mm x 6mm 3 AA
7- 6 XHTSD40P08RV0 J Screw: 4mm x 8mm 4 AA
7- 8 XEBSD30P06000 U Screw: 3mm x 6mm 2 AA
7- 9 XOTWW40P06000 U Screw: 4mm x 6mm 3 AA
7-10 XOTSD40P12RV0 J Screw: 4mm x 12mm 2 AA
7-11 XFPSD50P10KS0 U Screw: 5mm x 10mm 2 AB
7-12 LX-CZA001URE0 U Special screw: 4mm x 8mm 21 AA
7-13 XBPWW30P05K00 J Screw: 3mm x 5mm 2 AA
7-14 XEPSD40P25000 J Screw: 4mm x 25mm 2 AA
PARTS LIST
