R-775(W)R-785(AL) - 7
PRODUCT DESCRIPTION
SPECIFICATION
ITEM DESCRIPTION
Power Requirements 230 Volts / 50 Hertz / Single phase, 3 wire earthed
Power Consumption Microwave cooking 1.45 kW Approx. 6.5 A
Top Grill mode ...................... 1.25 kW Approx. 5.4 A
Grill cooking Bottom Grill mode................. 0.65 kW Approx. 2.8 A
Top and Bottom mode ......... 1.85 kW Approx. 8.0 A
Micro and Top Grill ............... 2.65 kW Approx. 11.7 A
Micro and Bottom Grill .......... 2.05 kW Approx. 9.1 A
Dual cooking Micro and Top and Bottom
mode(Auto cook only) ............ 3.4 kW Approx. 15.0 A
Power Output 900 W nominal of RF microwave energy (measured by method of IEC 60705)
Operating fequency 2450 MHz
Top Grill Grill heating element Power Output 1.2 kW
Bottom heating element Power Output 0.6 kW
Case Dimensions Width 520 mm Height 309 mm (including foot) Depth 437 mm
Cooking Cavity Dimensions Width 353 mm Height 207 mm Depth 357 mm
Turntable diameter 325 mm
Control Complement Twin-Jog Touch Control System
Clock (1:00 - 12:59 or 0:00 - 23:59) / Timer (0 - 90 minutes)
Microwave Power for Variable Cooking
Repetition Rate;
100%.................................Full power throughout the cooking time
70%.................................................. approx. 70% of FULL Power
50%.................................................. approx. 50% of FULL Power
30%.................................................. approx. 30% of FULL Power
10%.................................................. approx. 10% of FULL Power
LESS( )/ MORE( ) buttons , LANGUAGE button
EXPRESS PIZZA button , PIZZA button , FUN MENUS button
AUTO COOK button, AUTO DEFROST button, COOKING MODE dial
MICROWAVE POWER LEVEL button, +1 min button, STOP button
TIME/WEIGHT dial, INFO/CLOCK button, START button
Net Weight Approx. 17.5 kg
TEST DATA AT A GLANCE
PARTS SYMBOL VALUE / DATA
Fuse F1 20A / 250V
Fuse F2 F 8A
Thermal cut-out TC1 125°C Off
Thermal cut-out TC2 145°C Off / 115˚C On
Top grill heating element GH1 Approx. 44 Ω / Insulation resistance > 10 MΩ
Bottom grill heating element GH2 Approx. 92 Ω / Insulation resistance > 10 MΩ
Oven lamp OL 240–250 V 25W
High voltage capacitor C AC 2100V 1.13µF
Magnetron MG Filament < 1Ω / Filament – chassis ∞ ohm.
High voltage transformer T
Filament winding < 1Ω
Secondary winding Approx. 124 Ω / Primary winding Approx. 1.9 Ω
WARNING: DISCONNECT THE PLUG WHEN MEASURING RESISTANCE.
